Low power 24v 12v dc gear motor
LUNYEE GEAR MOTOR-DRIVING YOUR BUSINESS!
Low power 24v 12v dc gear motor
| MODEL | VOLTAGE | NO LOAD | AT RATED LOAD | AT STALL | Gearbox | |||||
| VDC | Length | |||||||||
| SPEED | CURRENT | SPEED | CURRENT | TORQUE | TORQUE | CURRENT | L | |||
| WORKING | NOMINAL | rpm | A | rpm | A | kg.cm | kg.cm | A | mm | |
| L-SGM51B-121200 | 9.0-28.0 | 12 | 1200 | ≤0.9 | 1000 | ≤7.0 | 3.9 | 17.7 | ≤0.7 | 37.5 |
| L-SGM51B-12700 | 9.0-28.0 | 12 | 700 | ≤0.9 | 600 | ≤7.0 | 5.8 | 29.7 | ≤0.7 | 37.5 |
| L-SGM51B-12375 | 9.0-28.0 | 12 | 375 | ≤0.9 | 280 | ≤7.0 | 12.5 | 59 | ≤0.7 | 37.5 |
| L-SGM51B-121 | 9.0-28.0 | 12 | 210 | ≤0.9 | 168 | ≤7.0 | 18.5 | 99 | ≤0.7 | 37.5 |
| L-SGM51B-12110 | 9.0-28.0 | 12 | 110 | ≤0.9 | 85 | ≤7.0 | 39 | 196 | ≤0.7 | 37.5 |
| L-SGM51B-1264 | 6.0-14.0 | 12 | 64 | ≤0.9 | 48 | ≤7.0 | 62 | 330 | ≤0.7 | 37.5 |
| L-SGM51B-1232 | 9.0-28.0 | 12 | 32 | ≤0.9 | 25 | ≤7.0 | 127 | 654 | ≤0.7 | 37.5 |
| L-SGM51B-1219 | 9.0-28.0 | 12 | 19 | ≤0.9 | 13 | ≤7.0 | 192 | 1000* | ≤0.7 | 37.5 |
| L-SGM51B-1210 | 9.0-28.0 | 12 | 10 | ≤0.9 | 7 | ≤7.0 | 400 | 1000* | ≤0.7 | 37.5 |
| L-SGM51B-1206 | 9.0-28.0 | 12.0 | 6 | ≤0.9 | 4 | ≤7.0 | 500* | 1000* | ≤0.7 | 37.5 |
| Note: | ||||||||||
| 1. This list is just for reference, we cam make the DC motor with Different voltage (6V, 9V, 12V, 24V), speed(from 1rpm-2000rpm), and also different Gear Ratio, so the Gear motor’s final output voltage, speed, torque can be customized. | ||||||||||
| 2. We can match different DC motor with this gearbox. | ||||||||||
| 3. Gearbox shaft dimension is adjustable. | ||||||||||
Low power 24v 12v dc gear motor
- 2-10pcs Samples of above standard parameters can be sent in 3-5days.
- Parameters and shaft size can be Customized. Non-standard prodcts can be sent in 15-25days.
- Processing according to Clients' samples or drawing is accepted.
Chengdu Lunyee Industries Development Co.,Ltd. is a leading manufacturer for AC gear motor, DC gear motor, high precision planetary gearbox for servo motor and stepper motor, linear motion products like linear bushing, linear guide, ball screw, locking nut and coupling and so on!
Low power 24v 12v dc gear motor
Please feel free to inform us your reqeust VOLTAGE,OUTPUT SPEED,TORQUE and QTY to get our information about sample, price, packing, leading time and any other related informations!
