Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice

Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice thumbnail-1
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice thumbnail-2
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice thumbnail-3
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice thumbnail-4
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice thumbnail-5
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice photo-1
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice photo-2
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice photo-3
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice photo-4
Wide Applcation Low Speed High Torque 24 Volt 12 Volt Micro Brush dc Gear Motor Quality Choice photo-5
US$ 6.6 - 10 MOQ: 2 Units
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
LUNYEE
Model Number:
L-SGM37-E
Contact Supplier Request Quote Chat Now
Chengdu Lunyee Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name LUNYEE
Model Number L-SGM37-E
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance, Other, Boat, Car, Electric Bicycle, Fan, Home Appliance, Electronic lock safe,electric vale and actuator,equipment apparatus
Certification CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, ISO9001
Type Other, Gear Motor, Massager 24 volt 12 volt dc gear motor
Torque 0.5-100kg.cm
Construction Permanent Magnet
Commutation Brush
Protect Feature Drip-proof
Speed(RPM) 1-1600rpm
Continuous Current(A) ≤0.29A
Output Power 0.5-80W
Voltage(V) 3-24VDC
Efficiency IE 2

Please Go to to download catalogue and get quotation for this model!



  Massager 24 volt 12 volt dc gear motor





Product Description





LUNYEE GEAR MOTOR-DRIVING YOUR BUSINESS!

                             wide applcation low speed high torque 24 volt 12 volt micro brush dc gear motor



Massager 24 volt 12 volt dc gear motor



wide applcation low speed high torque 24 volt 12 volt micro brush dc gear motor



MODEL VOLTAGE NO LOAD AT RATED LOAD AT STALL Gearbox
VDC Length
  SPEED CURRENT SPEED CURRENT TORQUE TORQUE CURRENT L
WORKING NOMINAL rpm A rpm A kg.cm kg.cm A mm
L-SGM37D-24600 12.0-28.0 24 600 ≤0.2 492 ≤1.0 2.4 12 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 300 ≤0.2 240 ≤1.0 4.7 24 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 200 ≤0.2 160 ≤1.0 7 36 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 120 ≤0.2 91 ≤1.0 11 60 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 86 ≤0.2 64 ≤1.0 15.5 84 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 67 ≤0.2 50 ≤1.0 20 108 ≤4.0 24.5
L-SGM37D-24600 12.0-28.0 24 50 ≤0.2 37 ≤1.0 25 144 ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 40 ≤0.2 29 ≤1.0 31 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 29 ≤0.2 21 ≤1.0 44 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 22 ≤0.2 15 ≤1.0 56 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 13 ≤0.2 9 ≤1.0 91 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 12 ≤0.2 8.5 ≤1.0 100* 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 9.5 ≤0.2 6 ≤1.0 100* 150* ≤4.0 29.1
L-SGM37D-24600 12.0-28.0 24 7 ≤0.2 4.5 ≤1.0 100* 150* ≤4.0 29.1
Note:
1. This list is just for reference, we cam make the DC motor with Different voltage (6V,12V, 24V), speed(from 1rpm-1600rpm), and also different Gear Ratio, so the Gear motor’s final output voltage, speed, torque can be customized.
2. We can match different DC motor with this gearbox.
3. Gearbox shaft dimension is adjustable.

  Massager 24 volt 12 volt dc gear motor


Our Services
  • 2-10pcs  Samples of above standard parameters can be sent in 3-5days.
  • Parameters and shaft size can be Customized. Non-standard prodcts can be sent in 15-25days.
  • Processing according to Clients' samples or drawing is accepted.
Massager 24 volt 12 volt dc gear motor

Company Information



 Chengdu Lunyee Industries Development Co.,Ltd. is a leading manufacturer for AC gear motor, DC gear motor, high precision planetary gearbox for servo motor and stepper motor, linear motion products like linear bushing, linear guide, ball screw, locking nut and coupling and so on!



wide applcation low speed high torque 24 volt 12 volt micro brush dc gear motor



  Massager 24 volt 12 volt dc gear motor


FAQ

 Please feel free to inform us your reqeust VOLTAGE,OUTPUT SPEED,TORQUE and QTY to get our information about sample, price, packing, leading time and any other related informations!
