Help CenterGXB2-BW3472 Push Button Switch
Related Products
Specifications
GXB2-BW3472 Push button switchInstall size: 22mm
OEM, ODM available
Competitive price, high quality
GXB2-BW3472 Push button switch
1. Specification
Model: GXB2-BW3472
Bezel type: metal
Install size: 22mm
OEM, ODM available
Competitive price, high quality
2. Working Environment
Working environment temperature: -25~+75°C
Storage temperature: -40~+70°C
Protection grade: IP40/IP65
Limit height: ≤2000M
Standard: EN 61947-1, GB14048.5
3. Main Technical Data
Rated insulation voltage
Rated thermal current: 10A
Switch rating: AC-15 Ue: 380V/250V, Ie=4.5A; DC-13 Ue: 220V/110V, Ie=0.6A
Contact resistance: ≤50mA
Recommended torque: 0.9Nm
Electrical life: ≥300000 times
4.Explanation of Type Designation
5.Contour of Type Designation
6.Products of Gaoqiao
7.From product development, design, procurement, manufacturing, inspection, service, all the
process Strictly controlled quality in every process, to ensure accurate,Every process inspection be strict
in one's demands, with action to practice the "customer in my heart,quality in my hand" the sincere
commiment, to provide customers with more, to satisfy every customer's requirements.
8.Zhejiang GaoQiao Electronic Co.,Ltd(GQ ELECTRONIC) has accumulated rih experience in product design and
manufacturing.In additional to the models and technical parameters provided by the company, it can deign and
manufacture according to the various requests of customers in order to satisfy and meet the customers' needs.
Over the years,the company adhere to the "science and technology inovation,sincere service" business
philosophy,won the praise of people from all the new and old customers. All the staff of Gaoqiao electronic co.
are full of confidence to explore and meet new opportunities and challenges and willing to work with customers
from home and abroad for a better tomorrow!
