2 position long lever rotary switch/selector switch

1. Model

• LA115-A1-11CX 2-position long lever selector
• LA115-A1-11CXS 3-position long lever selector
• LA115-A1-11CX/FU 2-position long lever momentary selector
• LA115-A1-11CXS/FFU 3-position long lever momentary selector

2. Feature

• Easy to Assemble
• Φ22mm, Φ25mm mounting diameter
• Choice of Plastic or Metallic Bezels
• Colour: R G Y B W BL
• Please indicate contact request. (Default contact is 1NO+1NC)

This series includes a complete range of push button switch, extended push button, illuminated

push button, maintained push button, Mushroom push button, emergency stop button, selector

switch, key switch, dual push button, and etc. For more information, please kindly check the other

types of LA115 series push button switches.

3. Application

Used to either close or open an electrical circuit. Used in various applications such as electric power

telecommunication, machinery, marine, textile, printing, miningindustrial equipment , and etc

4. Working Environment

• Ambient air temperature -25°c~ +40°c
• Altitude: ≤2000m
• Relative air humidity: ≤90%
• Pollution degree: class 3
• Protection degree: IP65

5. Main Technical Parameter

Rated value of switch: AC-15 36V/10A 110V/10A 220V/5A 380V/2.7A 660V/1.8A

                                    DC-13 24V/4A 48V/4A 110V/2A 220V/1A 440V/0.6A

Conventional thermal current: 1th 10A

Contact resistance: ≤50mΩ

Insulation resistance: ≥10mΩ

Mechanical durability:

common push-button≥100×104 times; selector button ≥30×104 times.

Key push-button≥5×104 times; Emergency push-button≥5×104 times
