Specifications
TFW Series Brushless Three-phase A.C Synchronous Generators1,Permanent Magnet generator
2.100% copper wire and 100% output
TFW Series Brushless Three-phase A.C Synchronous Generators
1,Permanent Magnet generator
2.100% copper wire and 100% output power
3.Single or Double bearing
Copy Leroy Somer Brushless Alternator (Single/ Double Bearing)
Warranty period:
Within 24 months from alternator's delivery or 18 months after the date first used, whichever comes first.
Accordant Standard:
GB755 National Standard for Rotating Electrical Machine
IEC60034 (International Electrotechnical Commission).
BS5000, VDE0530, CSAC22.2-100 International Standard.
Application Area:
Faraday alternators fit all different brands of engines, are extensively used as prime or standby power in various applications, such as
General industry, Mining, Military, Oil-field, Construction, Telecommunication, Hospital, Engineering Machinery, Building construction, CHP, Marine and other harsh environment applications etc
Additional Info.
Packing: Wooden case
Standard: 3 phase, 1500/1800rpm, 190-690V
Origin: FUJIAN, P. R China
HS Code: 85016100, 85016200
Factory Total Production Capacity: 30000sets/Year
100%output Wire: 100% copper wire
Product Description
Single bearing power alternator (TFW)
Rated ouput: 8kw-800kw /10kVA-1000kVA
Rated voltage: 230V/400V
Frequecny: 50Hz/60Hz
Speed: 1500rpm/1800rpm
Characteristics
1-Advance AVR control for troble-free operation under the most demanding condition
2-Easy paralleling with main or other generators
3-Standard 2/3 pitch windings avoid excessive neutral currents
4-Convenient installation and maintenace with easy access to terminals, rotating diodes device and couplings.
5-Wide range of flange adaptor and single bearing coupling disc.
6-Exciter's stator is equipped with permanent magnetic steel. It can make generator starting smoothly in any occasions.
| Model | Rated OUTPUT(KW) | Rated Capacity(KVA) | Rated Voltage(V) | Rated Current(A) | Regulat vol. adjust% | Power Factor (Cosφ ) | Rated Speed (r/min) |
| TFW-8 | 8 | 10 | 230/400 | 14.4 | 1 | 0.8 | 1500 |
| TFW-10 | 10 | 12.5 | 230/400 | 18.1 | 1 | 0.8 | 1500 |
| TFW-12 | 12 | 15 | 230/400 | 21.7 | 1 | 0.8 | 1500 |
| TFW-15 | 16 | 20 | 230/400 | 27.1 | 1 | 0.8 | 1500 |
| TFW-20 | 20 | 25 | 230/400 | 36.1 | 1 | 0.8 | 1500 |
| TFW-24 | 24 | 30 | 230/400 | 43.3 | 1 | 0.8 | 1500 |
| TFW-30 | 30 | 37.5 | 230/400 | 54.1 | 1 | 0.8 | 1500 |
| TFW-40 | 40 | 50 | 230/400 | 72.2 | 1 | 0.8 | 1500 |
| TFW-50 | 50 | 62.5 | 230/400 | 90.2 | 1 | 0.8 | 1500 |
| TFW-64 | 64 | 80 | 230/400 | 115.6 | 1 | 0.8 | 1500 |
| TFW-75 | 75 | 93.75 | 230/400 | 135.5 | 1 | 0.8 | 1500 |
| TFW-90 | 90 | 112.5 | 230/400 | 162.6 | 1 | 0.8 | 1500 |
| TFW-100 | 100 | 125 | 230/400 | 180.6 | 1 | 0.8 | 1500 |
| TFW-120 | 120 | 150 | 230/400 | 216.8 | 1 | 0.8 | 1500 |
| TFW-150 | 150 | 187.5 | 230/400 | 271 | 1 | 0.8 | 1500 |
| TFW-200 | 200 | 250 | 230/400 | 361 | 1 | 0.8 | 1500 |
| TFW-250 | 250 | 312.5 | 230/400 | 451 | 1 | 0.8 | 1500 |
| TFW-300 | 300 | 375 | 230/400 | 541 | 1 | 0.8 | 1500 |
| TFW-350 | 350 | 437.5 | 230/400 | 632 | 1 | 0.8 | 1500 |
| TFW-400 | 400 | 500 | 230/400 | 722 | 1 | 0.8 | 1500 |
| TFW-450 | 450 | 562.5 | 230/400 | 812 | 1 | 0.8 | 1500 |
| TFW-500 | 500 | 625 | 230/400 | 903 | 1 | 0.8 | 1500 |
| TFW-600 | 600 | 750 | 230/400 | 1084 | 1 | 0.8 | 1500 |
| TFW-720 | 720 | 900 | 230/400 | 1300 | 1 | 0.8 | 1500 |
| TFW-800 | 800 | 1000 | 230/400 | 1445 | 1 | 0.8 | 1500 |
Wooden case Package
100% copper and 100% output
