High Voltage Testing Equipment Differential Probe PT-5120(20KVp-p,20MHz)

High Voltage Testing Equipment Differential Probe PT-5120(20KVp-p,20MHz) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
pintech
Model Number:
PT-5120
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name pintech
Model Number PT-5120

high voltage testing equipment Differential probe PT-5120(20KVp-p,20MHz)







Model

PT-5120

Bandwidth (50Ωload)

20MHz

Accuracy

±2% ( Heat the machine after twenty minutes )

Switchable

X300,X600,X1500,X3000

Max. Operating Voltage

(DC+AC peak)

When X300, ≤2000V

When X600, ≤4000V

When X1500, ≤10000V

When X3000, ≤20000V

Max. input differential-mode voltage

20kV(DC+AC peak)

CMRR

60Hz:>20000:1

100Hz:>2000:1

1MHz:>600:1

Noise

≤2mVrms(50Ωload)

Input  impedance

118MΩ//1.2PF(Between both ends)

59MΩ//2.3PF(Single end to ground impedance)

Power source

9V(AC Adaptor)

power consumption

9V/35mA

contour dimension

235mm(L)X85mm(W)X35mm(H)

Weight

290g



 Contact me at any time



high voltage testing equipment Differential probe PT-5120(20KVp-p,20MHz)

high voltage testing equipment Differential probe PT-5120(20KVp-p,20MHz)high voltage testing equipment Differential probe PT-5120(20KVp-p,20MHz)
