oscilloscope test probe PT-8002(1400Vp-p,25MHz)
Specifications | |
Bandwidth |
25MHz |
Accuracy |
±2% |
Input Impedance |
4MΩ//5.5 p F each side ground |
Output Voltage | |
-Swing(into 50 KΩ load) |
±7V |
-Offset(typical) |
<±5mV |
-Noise(typical) |
0.7mV rms |
Power Requirements | |
-Standard |
4×AA cells or 6V DC/60m A mains adaptor or regulated 9V DC/40m A mains adaptor |
-Options |
power leads |
Weigh |
400g (probe and PVC jacket) |
Dimension(L×W×H) |
170mm×63mm×21mm |
Specifications |
PT-8002 |
Attenuation Ratio |
1:20/200 |
CMRR(typical) |
-80dB@50Hz,-60dB@20kHz |
|
Differential Input Voltage (DC+ Peak AC) |
|
|
Common Mode Voltage (DC +Peak AC) |
1400V@1/20 & 1/200 |
|
Absolute Max .Input (Each side to ground) |
1000V rms CAT Ⅲ |
Features |
·Up to1400V(DC+ Peak AC) Differential and Common Mode ·Safety Certified ·Economical Cost |
|
Applications |
·Switching Power Supply Design ·Motor Drive Design ·Electronic Ballast Design ·CRT Display Design |
