high quality stainless steel glycerin filled air conditioning pressure gauge

Specifications

high quality glycerin filled mini pressure gauge
1. High quality pressure gauge
2. Advanced equipment
3. 100% inspection
4

High quality Oill filled pressure gauge

ZD-N series products brief introduction

ZD-N series products are filled with damping liquid good  performance of shock proof.This sort of maters  is suitable for locations  where the  pressure  of  medium  changes intensely  and pressure shock proof exists, or pressure is released suddenly in the course of manufacturing, or working environment shock largely. The meter can measure average of gas and liqu id mediums.Thus damage to  meter induced byintensive fluctuation and environmental shock can be over come smoothly and accuracy  of freading is ensured.

Application

Process industry, Chemical/petro-chemical, Power stations, etc.

The specification in the same series:

Nominal Size:	1.5"(40mm),2"(50mm),2.5"(63mm),3"(75mm),4"(100mm),6"(150mm)
Pressure ranges:	-1~0bar to 0~400bar
Case:	stainless steel
Accuracy class:	1%, 1.6%, 2.5%
Threads sizes:	1/8, 1/4, 3/8 and 1/2 inches
Thread standard:	NPT, BSP (G, PF), BSPT (ZG, PT)
Connection mounting:	bottom, top, left, right and center back
Burdon tube:	stainless steel, phosphor bronze
Movement:	brass or stainless steel
Dial,Pointer:	Aluminum
Welding:	TIG ,Laser Welding
Window(lens):	tempered glass, polycarbonate
Fill:	glycerine(standard),Silicone(optional)
Working temperture:	-20°C- 70°C
IP class:	IP 65

 The items in the same series:

Model	Dial Type/Diam.	Accuracy	Case Material	Connection Material	Conn.Type/Size	Fill
ZD-N40	Radial or axial / 1.5''	±2.5%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/8	Glycerin
ZD-N50	Radial or axial / 2''	±2.5%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/4	Glycerin
ZD-N63	Radial or axial / 2.5''	±2.5%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/4	Glycerin
ZD-N75	Radial or axial / 3''	±2.5%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/4	Glycerin
ZD-N100	Radial or axial / 4''	±1.6%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/2	Glycerin
ZD-N150	Radial or axial / 6''	±1.6%	Stainless steel	Brass Or Stainless steel	Threaded Connection 1/2	Glycerin

Note: The requirements can be customized,you may tell us the pressure range, diameter, accuracy, mounting, and other related parameters.

Packing detail:

Our services:

Based on the advanced equipment, high technology, serious inspection procedure, best after-sales service, our professional level and unremitting efforts, gaining the best reputation and response from the customers.

In order to ensure the quality of the products, our manufacturing facility in China is ISO9001 certificated and always in line with quality first .

From the raw material to the finished production we have the very strict and serious procedure to guarantee our products get to the different quality requirements to provide our customers high quality products, first-class service.

Company information:

Yuyao Zend Instrument Factory is a production of the barometer, seismic table, steel table, hydraulic meter, gas meter, pipeline valve pressure gauge, vacuum gauge... And other products, sales in Asia, the Middle East, Europe, Latin America and other regions; specifications complete, widely used in pneumatic,hydraulic, water, oil, chemical, metallurgy, machinery, food, gas, valve, pipe and other industries; products by the broad masses of customers.

Companies adhere to the "sincerity casts reputation, professional build quality" business philosophy, that customer is the product quality of the referee. Proceed from the personnel, equipment, management, strict each link, so as to guarantee the quality of products talent showing itself in the many brands, to win the trust of customers, at all times to the integrity of service in the first place, improve product quality at the same time, to improve their service repair ability,Zend each kind of products recommended to customers, let customers without fault.. has a complete, scientific quality management system.

Yuyao Zend Instrument Factory integrity, strength and quality of products recognized by the industry. Welcome all friends to visit, guidance and business negotiation.

Our advantages:

Why choose us? ------- Yuyao Zend Instrument Factory

------------------------------------------------------------------------------------------------

1) Advance Equipment and Professional Technology: we are committed to offer the good quality gauges with advance equipment and professional technology for all over the world customers.

2) Best After-sales Service : Our company provide best after-sale service all the time , for our goal is a long trade cooperation term.

3) Serious Inspection Procedure with Excellent Quality: Our pressure gauges all are 100% inspection , we also have passed ISO9001 and UL certificated.

4) Quickly Delivery: Our company provides in-time delivery with , always satisfy customers needs.

5) Convenient Purchase and save cost: Zend is a direct exporter and skillful manufacturer, so it's convenient for you to purchase , We can provide our high quality products with reasonable price.

6) Best Reputation : Our factory have 5 years experiences and have already gaining the best reputation and response from the customers from all over the world.

7)OEM orders: In the past years, we have many OEM orders from very famous company in USA and European market .



FAQ:

1. What's your minimum order quantity ?
We have no limits about MOQ, we can sell product to you even you just want 1 piece.

2. How about the usual delivery time?
We will send goods to you within 15 working days.

3. What terms of payment are available?
TT, Paypal, LC.

4. What detailed informations do we need if you want to order our procduct ?
Pressure range, diameter, accuracy, mounting, and other related parameters.

5. Does quantity affects price?
Yes. For larger quantities, we will give you some discount.
