Help Center5-14*2000 Steel Coil Slitting Line
Related Products
-
1600mm Steel Coil Slitting LineUS$ 90,000 - 300,000MOQ: 1 Set -
2000mm Slitting LineUS$ 156,000 - 300,000MOQ: 1 Set
-
Steel Sheet Slitting LineUS$ 50,000 - 150,000MOQ: 1 Set
-
3-14X1800 Steel Coil Slitting LineUS$ 500,000 - 600,000MOQ: 1 Set
-
3-14X1800 Steel Coil Slitting LineUS$ 500,000 - 600,000MOQ: 1 Set
COMPANY DESCRIPTION
Our company is a professional manufacturer of roll profile high-frequency welded pipe equipment, four roller cold rolling mill, high-speed shear equipment, precision cold forming equipment, stainless steel welded pipe equipment and all kinds of complicated cross-section. It is one of the earliest domestic special factories that are engaged in making welded pipe equipment in China.
PRODUCTION PROCESS
Coil loading car
uncoiling
Pinch leveling
Cut to length
Centering guide device
Disk shear
Waste edge reeling
Ground accumulator
Tension device
Recoiler
Discharging car
Electronic control system
Hydraulic system
TECHNICAL PARAMETERS
1. RAW MATERIAL SPECIFICATIONS:
Coil OD: Max. Φ2000mm
Coil ID: Φ508~Φ760 mm
Coil width: 1000~2500mm
Coil thickness: 3.0~16.0mm
Materials: Q235, Q345B
Coil weight: Max.30T
2. SLITTING SPECIFICATIONS:
slitting speed: 15~40m/min
3. PRODUCT QUALITY AND STANDARD
After slitting, strip quality should comply with the provisions of GB/T709-2006.
After slitting, the deviation of strip width allowed -0.5 mm~+0.5mm.
Burr and convex platform≤0.1mm
Longitudinal and lateral bending 1mm/m/m
Edge cutting slope: wall thickness<10 mm, edge cutting slope<0.2mm;
10mm<wall thickness<14mm, edge cutting slope<0.3mm
Amount of interlayer wrong side≤1mm
Tower deviation≤3mm
Surface quality: No visible scratches
DELIVERY
Shipment of goods in accordance with equipment list within 8 months starting from the next day of contracting and receiving down payment.
PAYMENT TERMS: T/T or irrevocable L/C
PACKING: electric control part packed in wooden case, remaining nude packed.
AFTER-SALES SERVICE
The supplier will send technical persons to buyer’s site to carry out installation & testing and provide technical support. Relevant expenses shall be borne by the buyer. During testing, the buyer shall provide required plant building & equipment, testing material and manpower support.
