This line is used for uncoiling, flattening, cutting, stacking for the hot rolling coil with the thickness of 1~6mm, and the width of 800mm~2000mm.
Process flow:
Coil storage→coil loading→uncoiling→guiding→flattening→feed-to-length→strip shearing→strip transport & kickoff→pallet lifting→longitudinal moving and stack output
2000 Slitting Line Parameters:
Specification: 2000×16
Max. Width:1800mm
Thickness:4-16mm
Materials: Q235,Q345B,J55,X70,X80
Welding Speed:20-40m/min
Width Quantity Materials
4mm 8 strips Q235,Q345
12.7mm 3 strips X70
16mm 2 strips Q235,Q345
DELIVERY
Shipment of goods in accordance with equipment list within 3-4 months starting from the next day of contracting and receiving down payment.
1. PAINTING
Equipment surface shall be coated with antirust paint. Paint color can be decided by the buyer or by the supplier on his discretion.
2.FOUNDATION WORK
The supplier will provide the buyer with foundation drawing of the equipment, with construction and supervision of foundation at the buyer’s own responsibility.
The client shall prepare plant building, equipment foundation, and cooling water pool as per equipment data provided by the supplier. Necessary installation apparatus (lifting rig, tools), installation accessories (wires, conduits, water pipes), and helping labors shall be arranged by the client.
The client shall provide water supply, power supply, and air supply to machine interface.
3.WARRANTY
The warranty will cover a period of one year starting from delivery for machines under normal operation conditions (Force Majeure excluded).
