Latest Powder Raymond Mill Machine for Mining and Constrution

Name: Latest Powder Raymond Mill Machine for Mining and Constrution
Brand: Dingbo Machinery
SKU: 116658489
Availability: InStock

US$ 110,000 - 120,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Powder Grinding Mill, Pulverizer

Application:

chemical and papers, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones

Shanghai Dingbo Heavy Industry Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Powder Grinding Mill, Pulverizer

Application chemical and papers, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones

Motor Type AC Motor

Power(W) 75

Capacity(t/h) 20

Place of Origin Shanghai, China

Brand Name Dingbo Machinery

Model Number MTM160

Dimension(L*W*H) 1150x1275x1240mm

Weight 20t

Certification ISO,CE

Warranty 1Year

After-sales Service Provided Engineers available to service machinery overseas

Latest Powder Raymond Mill Machine for Mining and Constrution
The grinding processing materials can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic, aluminum bauxite, manganese ore, iron ore, copper ore, phosphate rock, red iron oxide, zircon sand, slag, cement clinker, activated carbon, dolomite, granite, garnet, iron oxide yellow, bean cake, chemical fertilizer , compound fertilizer, fly ash, bituminous coal, coke, lignite, Ling U.S. sand, chromium oxide green, gold,fluorspar, bentonite, , thermal insulation, materials in the 9.3 Mohs hardness below 6% moisture in a variety of non-explosive mineral materials processing.




Shanghai Dingbo Grinding Mill Features
1.The MTM160 Mill grinding roller pressure on the material under the action of the spring in the high-pressure increase 800 - 1200kg. 2.The MTM160 Mill on the Mohs hardness of less than 9.3 processing of mineral materials can be crushed. 3.The MTM160 Mill wide range of product particle size, particle size up to 0.613 mm the thickest (30 mesh) particle size of generally up to 0.033 mm (425 mesh), few materials can reach 0.013 mm the smallest (1,000 head).

DBM MTM160 Grinding Mill Technical Parameters List
Item				High Pressure Grinding Mill(Powder Raymond Mill)
Model				MTM160
Roller(pcs)				6
Diameter(mm)				Φ440
Roller Height(mm)				270
Inner Diameter(mm)				160
Ring Height(mm)				270
Max Input Size(mm)				35
Discharging Size(mm)				0.613-0.033(80Mesh-325mesh)
Capacity(t/h)				5-20/h
Motor(kw)				132
Overall Dimension(mm)				12550×5700×8350
