Product Description of Waste oil regeneration plant
♥. Waste oil regeneration plant can be applied to regenerate all kinds of waste lubricating oil(including petrol and diesel oil and any kinds recoverable waste oil).
No secondary pollution during the process, No waste gas or water released into the atmosphere,the residue created during can be used as fuel.
♥. Waste oil regeneration plant can be used in black engine oil,Crude oil and plastic oil, to get gasoline and diesel oil through distilled catalyst. Pumping into the heater with Waste oil which can be pretreated, through the coal (or fuel oil,gas) heating to working temperature,the maximum working temperature is about 410 degree and the required gasoline and diesel oil can be obtained after catalytic distillation. When the reaction of waste oil in reactor is complete, stop heating, and remove residue from the tank of bottom, then this machine can be used again.
Quarantee of Waste oil regeneration plant
Overall quality assurance two years (except wearing parts under normal operation, free maintenance), life long maintenance. Host the Q245R boiler steel plate, can bear high temperature 700 ℃.
Application and raw materials of Waste oil regeneration plant
NO. |
Raw Material |
Note |
1 |
Waste engine oil |
All kinds of liquid oil will be OK, Just the oil yield is different, please tell us your raw material, our engineer can test the oil yield for you before make order. |
2 |
Tyre oil |
|
3 |
Plastic oil |
|
4 |
Waste crude oil |
|
5 |
All kinds of fuel oil |
|
6 |
All kinds of heavy oil |
|
7 |
lubricating oil |
Mani parts of Waste oil regeneration plant
♥. Reaction tank: waste oil will be pumped into this tank after pretreated.
♥. Heating system: through burning coal or fuel oil to make the oil temperature up to setting value. this system equipped with insulation system.
♥. Catalytic system: waste oil reaches the predetermined temperature, via catalytic effect, then the gaseous hydrocarbons will become gasoline and diesel composition.
♥. Cooling system: gasoline and diesel after catalytic effect can be condensed into liquid materials.
♥. Temperature control system: ensure that waste oil transform into gasoline and diesel oil, waste oil drying by distillation, can stop heating timely.
♥. Exhaust gas handling system: a small amount of not liquefied gas via treated, can meet emission standards.
♥. Unique technology for increasing the oil output (the oil yield is not less than 90% when the water by extraction is less than 5%.
Reducing the fuel consumption (20 kg diesel for each ton of wast oil) and preventing coked.Durning the processing with high tech pyrolysis oil fefining 3.we are good at reducing the sulfur, cloud point and color of the oil, which can be provided separately with additional cost.
Competetive Advantages of Waste oil regeneration plant
♥. 100% Avoid burn technologyexplosion-proof technology for 100%
♥. With auto welding machine for tire oil machinery, it can not only greatly improve working efficiency but also guarantee the welding quality.
♥. Professional thermometer, pressure gauge and safey explosion-proof valve.
♥. It is dangerous to burn exhaust gas (C1 to C4) without any safety measures. but we special design which is hydroseal and gas gun .It is not only guarantee the safety but also can save the fuel.
♥. The third generation of heating method which combines the advantages from direct and indirect heating . It is safe for the operation.
♥. Equipped with anti-explosion device, safety valves, energency valves, pressure and temperature meters, as well as the alarming system, which will ensuer 100% seurity.
The technical parameter of Waste oil regeneration plant
Items |
Waste oil regeneration plant |
||||
Raw material |
Tyre oil, Raw oil, waste engine oil, waste washing oil |
||||
Structure form |
Horizontal |
||||
Model |
YX-1 |
YX-2 |
YX-1 |
YX-2 |
YX-3 |
Size of reactor(mm) |
1600*4400 |
2200*5100 |
3000*5000 |
(3600*6000)*2 |
(3600*6000)*2 |
24-hour capacity |
6T |
10T |
25T |
50T |
100T |
Operating pressure |
Constant pressure |
||||
Heating material |
Coal, charcoal, fuel gas, fuel oil |
||||
oil out-put oil rate |
80%-90% (Depend on the material) |
||||
Material of reactor |
Q245R/Q345R boiler plate |
||||
Thickness of reactor |
16mm |
||||
Reactor rotate speed |
0.4-0.8 turn/minute |
||||
Mode of cooling |
Water cooling |
||||
Power in total |
4.0-8.0kw |
||||
The technological process of Waste oil regeneration plant
♥. pump crude oil into refining tank and heat with conduction oil, and the temperature will reach about 70°C-80°C after one hour.
Add acid or alkali to separate according to the acid value. After one hour's processing and 4-6hours deposit, then convey soap stock to storage tank.
♥. Pump refined oil into decoloring tank. When it is up to 90-110°C after one hour's heating, add clay into tank for 20min's processing. Then separate clay and oil with filter.
♥. Put discolored oil into deodorization tank with vacuum pump. Heat and process with steam for odor removal. After filtering, you will get final oil product.
Packing&Shipping of Waste oil regeneration plant
We can offer standard exporting packing for long distance sea transportation, wooden case with steel frame, it not only can protect machi Small hydraulic interlocking brick machine ne from damage, but also can guarantee smoothly pass the exporting inspection.
Our thoughtful service of Waste oil regeneration plant
Why us?
♥. How about the quality of machines?
Our machines adopt advanced technology. Moreover, we carry out strict supervision during production and make sure every finished product with high quality.
♥. About the delivery time?
Generally, it will be about 20-25 days days after your deposit, which also will be on basis of your order.
♥.What is the packing for machine?
It depends on your ordering quantity. For sample orders, we advise iron case or plywood case packing to protect the machine from damaging during loading and shipping. For full container load orders, nude packing is ok.
Welcome to visit our factory and test our machines.
Thank you!
