Packaging & Delivery
| Packaging Detail: | 1pcs media converter,1pcs power adapter,user's manual in one pack box. |
| Delivery Detail: | in 7days for 1000pcs |
Specifications
100M ethernet converter
10/100M cassette multimode fiber optic mediaconverter module wavelength 1310nm typical distance 100km
100M ethernet converter
Technical parameter
1.According with IEEE802.3 IEEE802.3u IEEE802.3X IEEE802.1Q 100Base-TX 100Base-TX 100Base-FX standard.
2.Afford TCP/IP,PPPOE,DHCP,ICMP,NAT protocol.
3.Flow control:full-duplex adopt IEEE802.3x,half-duplex adopt Backpressure standard.
4.Electric port support auto-negotiation function,autoconditioning transmit mode and transmit speed.
5.Port supply Auto-MDI/MDIX automatic reverse.
6.Support storage transmit mode.
7.Support electric port's 10M 100M mode and self-adapt mode to switch.
8.Afford the state indicator,external power(output 5V~50HZ 1A)
9.Interface:electric port:RJ-45 fiber port:SC
10.Twisted-pair:Cat5 Cat6
11.Singlemode fiber: 8/125,8.3/125, 9/125µm
12.Working temperature:0~50 degree
13.Storage temperature:-20~70 degree
14.Humidity:5%~90%(noncondensing)
15.Size:27*86*118mm(H*W*L)
16.Lightning protection.
Basic features:
Item |
Specification/Term |
|
1 |
Item number |
APT-103 Series |
2 |
Standard |
IEEE802.3,IEEE802.3u,10/100Base-TX,100Base-FX |
3 |
Flow control |
IEEE8.2.3x port flow control and backpressure control |
4 |
Transmission speed |
10M/100M auto-negotiation |
5 |
Transmission mode |
Full-duplex and semi duplex(auto-negotiation) |
6 |
Conversion mode |
Media conversion, storage transmission, direct transmission |
7 |
MAC address |
1K |
8 |
Buffer space |
288KB |
9 |
Packet length |
Storage transmission:2046Bytes,straight-through,infinite. |
10 |
Time-delay |
9.6us |
11 |
Bit error rate |
<1/1000000000 |
12 |
MTBF |
100,000 hours |
13 |
Power supply |
AC100~265V 50/60Hz / DC5V 1A |
14 |
Power dissipation |
<2.5W |
15 |
Interface |
Electric port:RJ45,Fiber port: SC/FC |
16 |
Twisted-pair |
Cat.5, Cat.6, directs wire and cross wire. |
17 |
Multimode fiber |
50/125,62.5/125um |
18 |
Single mode fiber |
8/125,8.3/125,9/125um |
19 |
Wavelength |
850nm/1310nm/1550nm |
20 |
Transmission distance |
|
|
1)dual fiber multimode |
550M/2Km |
|
2)dual fiber single mode |
20/40/60/80/100/120Km |
|
3)single fiber single mode |
20/40/60/80Km |
|
4)Cat.5 twisted-pair |
100m |
21 |
Operating temperature |
0~50°C |
22 |
Storage temperature |
-20~70°C |
23 |
Humidity |
5%~90% (no condensation) |
24 |
Size |
95*70*26mm (L*W*H) (external power supply) 140*110*30mm(L*W*H)(Built-in power supply) 115*88*25mm(L*W*H)(Built-in power supply) 117*86*27mm(L*W*H)(Built-in power supply) 158*128*32mm(L*W*H)(Built-in power supply) |
Global exhibitions:
Please don't hesitate to contact us .skype:apt.8866
