Shenzhen 20 km bnc to fiber converter
Application field
Intelligent Transportation System
Connection of Sub-network for Surveillance Center
Public Security Surveillance
High way&Toll Station Surveillance
High Quality Video Conference
Industrial Closed Circuit Television Surveillance
TV-live,audio,phone,ethernet,transmission
Shenzhen bnc to vga converter bnc to rj45 converter video digitsl optical converter
Specific details:
| Video port QTY | 2 channel video |
| Video port type | BNC |
| Input/output inpedance | 75 Ω(unbalance) |
| Input/Output voltage | 1 Vp-p(Peak-peak) |
| Video banwidth | 8 MHz |
| Sampling rate | 16 Mhz high speed |
| Differential gain | (10-90 % APL)DG<1%( typical ) |
| Diferrential phase | (10-90 % APL)DG<o0.7°(typical ) |
| Video SNR(Weighting) | S/N ≥ 70 dB(Max optical link loss) |
| Work temperature | -20~70 ℃ |
| Storage temperature | -40~85 ℃ |
| Relative humidity | 0~95 %(No condesation) |
| Size | Wall-hung 70*95*26 mm |
| Power supply | AC 85 V~265V/DC 5 V |
| Power rate | 2.5 W |
| MTBF | ≥ 10,000 hours |
Shenzhen bnc to vga converter bnc to rj45 converter video digitsl optical converter detail image
Shenzhen bnc to vga converter bnc to rj45 converter video digitsl optical converter related product
| Poduct model | Pack type | Description | Reach distance |
| APT-201F/D02V1D-WSX | Wall-hung type | Multi-mode 2 channels video +1 reverse data | 0-2 km |
| APT-201F/D02V1D-WSX | Wall-hung type | Single-mode 2 channels video +1 reverse data | 0-20 km |
| APT-201F/D02V1D-WSX | Wall-hung type | Single-mode 2 channels video +1 reverse data | 0-40 km |
| APT-201F/D02V1D-WSX | Wall-hung type | Single-mode 2 channels video +1 reverse data | 0-60 km |
Shenzhen bnc to vga converter bnc to rj45 converter video digitsl optical converter package and delivery
Package
1.Main body *1
2.Instrucation *1
3.Charger * 1
4.Warrant card *1
All this in a shockproof and Specially crafted case
Payment
1.T/T
2.Paypal
3.Western Union
Shipping
By air,sea and express,we will choose the best way for your delivery.
APT prosper Technology Co.,Ltd was founded in 2004,located at the central part of Futian District,Shenzhen.We are a high tech enterprise and specialize in the research,production marketing and service in optical communication field with our independent brands APTTEK.Main product are:Ethernet media converter,Digital video optic transceiver and optical module.
With the unceasing development,APT provide service and management with the purpose of MUTUAL BENEFITS and the mission of SKILL IN QUALITY SEPCIALIZED IN SERVICE,offering best service and exquisite products to you-our honored customers.
To make the quality guaranteed and improvement,we strictly operated according to the ISO9001:2008 quality control system,CCC,CE standard.We pay great attention to the cultivation of talents,maximizing the employees potential with humanized management to boost staffs greatly;and providing a comprehensive training and guidance,continuously improving our process increase efficiency and reduce the waste to strength competitive power.Our constantly introducing data and video optical transmissions are widely used among the domestic operators and industry users with customer’s praise.The strategy of going out,our oversea sales department successful enlarge overseas users as a global partner.
Our goal is continuously satisfy our customers,provide high quality products and services to global partners,with first class technical support and solutions promote the development of the information of the information net construction.
Q1 . What your MOQ?
A1 :1 pcs is ok,whatever how many you need,and we will also give you the best service.
Q2.What certification did you get?
A2 : Our product strict operate the ISO9001:2008 quality control system and we passed the CE,CCC,ROHS and SGS test,you can trust us.
Q3 :What about your package and delivery,will it broke during shipping?
A3:You don't need to worry about the package,we will use shockproof case for delivering.
Q4.What your common delivery way?
A4:By air,sea and express(Ups,Fedex,TNT,EMS...)We will make a perfect delivery plan for you.
Q5.Tell me some detail about warrant time.
A5:We give you the promise if any question during 1 year and not cause by human factors,we will fix it.
Any question,leave me an inquiry or contact me directly.
What's app and we chat:+86 13005471327
Skype:apt.8866
