1000M Sfp ethernet media converter fiber ethernet switch
Item Name |
media converter |
Standard |
IEEE802.1q,IEEE802.3u,10/100/1000 Base-T,100Base-FX 1000 Base-SX/LX,IEEE 802.3ah,Ieee802.1D |
Flow control |
IEEE8.2.3x port flow control and backpressure control |
Transmission speed |
10/100/1000 M auto-negotiation |
Conversion mode |
Modified cut-through,store and forward,converter mode |
MAC address |
VLAN 4k |
Buffer space |
128 K |
Packer length |
Store forward:9728 Bytes,Converter mode,infinite |
Time-delay |
9.6 us |
Bit error rate |
<0.000,000,000,1 |
MTBF |
100,000 hours |
Power supply(External) |
AC100~265V,50/60 Hz/DC5V 1 A |
Power rate |
< 2.5 W |
Connector |
RJ 45/SC&FC/SFP |
Twisted pair |
Cat.5,Cat.6 |
Mutilmode fiber |
50/125,62.5/125 um |
Single mode fiber |
9/125 um |
Reach distance |
|
Mutilmode |
550 m |
Singlemode |
20/40/60/80 km |
Cat.5 twisted-pair |
100 m |
Operating temperature |
-20~70 Celsius |
Stroage Temperature |
-20~70 Celsius |
Humidity |
5~90% |
Size |
95*70*25 mm(External power supply) |
|
140*70*25 mm(Built-in power supply) |
|
115*88*25mm(Card without metal box) |
Package:
Main body *1
Manual *1
Adapter * 1
Warranty card *1
All this in a carton case
Delivery:
Leading time:5~15 working days
Delivery way:By air,sea and express(DHL,EMS,Ups,Fedex,Tnt)
Payment:
T/T,Paypal,Western Union
Q1 . What your MOQ?
A1 .1 pcs is ok,whatever how many you need,and we will also give you the best service.
Q2.What certification did you get?
A2 : Our product strict operate the ISO9001:2008 quality control system and we passed the CE,CCC,ROHS and SGS test,you can trust us.
Q3 :What about your package and delivery,will it broke during shipping?
A3:You don't need to worry about the package,we will use shockproof case for delivering.
Q4.What your common delivery way?
A4:By air,sea and express(Ups,Fedex,TNT,EMS...)We will make a perfect delivery plan for you.
Q5.Tell me some detail about warrant time.
A5:We give you the promise if any question during 1 year and not cause by human factors,we will fix it.
Any question,pls leave me an inquiry or contact me directly .
What's app and we chat:+86 13005471327
Skype:apt.8866
