42" Industrial LCD CCTV Monitor (Industrial Metal Case)
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Screen Size:
Other, 42"
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
32" Industrial LCD CCTV Monitor (Industrial Metal Case)US$ 1 - 2MOQ: 1 Piece -
26" LCD CCTV Monitor (Industrial Metal Case)US$ 1 - 2MOQ: 1 Piece
-
70"Industrial LCD CCTV Monitor (Industrial Metal Case)US$ 1 - 2MOQ: 1 Piece
-
46" Industrial LCD CCTV Monitor (Industrial Metal Case)US$ 1 - 2MOQ: 1 Piece
-
82" LCD CCTV Monitor,1920*1080,support VGA,YPbPr (BNC),CVBS (BNC) Signal InputUS$ 1 - 2MOQ: 1 Piece
Products Status
Stock
Application
Desktop
Screen Size
Other, 42"
Response Time
5ms
Brightness
450cd/m
Interface Type
DVI, HDMI, Other, DVI, HDMI, VGA,YPbPr (BNC),CVBS (BNC)
Contrast Ratio
Other, 1300:1
Resolution
1920 x 1080
Panel Type
TFT
Pixel Pitch
0.4845(H) x 0.4845(W)
Brand Name
NODKA
Model Number
ND-PM-420NX
Place of Origin
Shanghai, China
| 42" Industrial LCD CCTV Monitor (Industrial Metal case) / TFT LCD CCTV Monitor with BNC VGA HDMI | ||
| Product Description | ||
| Panel (TFT LCD panel) | Diagonal Size | 42" |
| Aspect Ratio | 16:9 | |
| Pixel Pitch | 0.4845(H) x 0.4845(W) | |
| Response Time | 5ms | |
| Resolution | 1920x1080 | |
| Contrast Ratio | 1300:1 | |
| Brightness (cd/m2) | 450d/m2 | |
| Active display area | 930.24 (H) x 523.26(V) | |
| Display Color (Max) | 16.7M | |
| Viewing Angle(U/D,L/R) | H:178o V: 178o | |
| Lifetime | More than 50,000 hours | |
| Inputs | VGA | X1 |
| DVI | X1 | |
| HDMI | X1 | |
| YPbPr (BNC) | X1 | |
| CVBS (BNC) | X5 | |
| Audio in (VGA & DVI) | X1 | |
| Audio in (AV & YPbPr) | X1 | |
| RJ45(for RS232 in) | X1 | |
| Outputs | RJ45(for RS232 out) | X1 |
| CVBS (BNC) | X2 | |
| Features and Benefits | 1. Full HD LCD panel with 1920x1080 resolution, viewing angle: 178o (H/V)450 nits birhgtness, high contrast ratio and colour saturation | |
| 2. Metal case: anti-static, antimagnetic, anti-interference, damage-proof performance. Compatible with VESA standard. | ||
| 3. Designed and engineered for 24/7 operation. Long lifetime: >50,000 hours. | ||
| 4. Professional driving IC (adopting 3D comb filter and digital noise reduction technologies), ensuring high quality and stable colour performance. | ||
| 5. Built-in temperature sensor results in smart fan&work temperature control. | ||
| 6. Energy saving, very eco-friendly low power. | ||
| 7. HDMI, VGA multiple I/O ports allow for greater compatibility and flexibility. | ||
| 8. Various installation methods: wall mount, floor stand, cabinet-mount etc. | ||
| 9. Operation modes: RS232, IR remote control, Key control | ||
| 10. Ideal LCD monitor for CCTV, SCADA etc. automation system | ||
| Product functions | Anti-static, antimagnetic anti-interference | √ |
| Built-in temperature sensor, smart fan | √ | |
| Eco-friendly low power | √ | |
| PIP/POP | √ | |
| Pixel shifting | √ | |
| Auto image adjust (position/color etc.) | √ | |
| Manual image adjust (position/color etc.) | √ | |
| White balance adjustment | √ | |
| ADC Signal Conditioning | √ | |
| 3D decoding | √ | |
| 3D comb filter and digital noise reduction | √ | |
| Double 3D De-interlacing | √ | |
| 3D Y/C separation | √ | |
| 3D Color Management | √ | |
| 3D Marginal sawtooth finish | √ | |
| 3D image static/dynamic compensation | √ | |
| Picture Freezing | √ | |
| Mechanical Spec | Hole for wall mount | Refer the technical drawing |
| NW/GW | 20.5kg/28kg | |
| Dimension(W/O stand) | 996×595×118mm | |
| Packing Dimension (1 pcs/ctn) | 1180x775x250mm | |
| Power | Power supply | AC Input 100~240V(+/-10%)/50-60Hz |
| Power consumpiton | ≤220W | |
| Stand-by | ≤2W | |
