Specifications
metal tube/pipe laser cutting machineHigh cutting precision, Fast speed
Automatic metal tube cutter
Low maintenance cost
metal tube/pipe laser cutting machine
High power YAG laser cutting machine for sheet metal and metal tubes with high precision and high speed
Machine Features
1. High metal tube cutting precision: precise cutting for various precision parts, arts and crafts.
2. Fast speed: 100 times higher than linear cutting.
3. Small heat affected zone, good dimension stability. Smooth and beautiful cutting edges do not need later processing.
4. Competitive price: the price is only 1/3 of the similar CO2 laser cutting machine and 2/5 of the NC Punch.
5. Low use cost: only USD2-USD5 per hour which is 1/8-1/10 of the similar CO2 laser cutting machine (USD22-USD35 per hour).
6. Low follow-up maintenance cost: only 1/10~1/15 of the similar CO2 laser cutting machine and 1/3~1/4 the NC Punch.
7. Steady performance: as one of the most stable and mature laser apparatus in the laser field, the YAG laser cutting machine is suitable for long time continuously production.
8. Compared with CNC Punch machine, YAG laser cutting machine have many advantages:
(1) Any complicated structure which can be drawn on the computer can be manufactured by CNC YAG laser cutting machine.
(2) If the product image has be drawn on the computer, the product can be manufactured immediately without opening mould technology. It can be used to develop new products rapidly and reduce cost.
(3) Both 2D &3D cutting and surface trimming can be finished by automatic tracing system of YAG laser cutting machine.
(4) Laser cutting machine can accomplish the complicated process which is hard to achieve by NC punch.
(5) The machine can make high grade production with smooth surface, which is hard to obtain by NC punch.
(6) Forming the body (the height should be within 0.5 meter) which need increase the slot-hole processing can be achieved by YAG Metal Laser Cutting Machine, while CNC punching machine cannot do it.
Application Field
The exchange of cutting methods between metal pipe and metal sheet can be achieved by our metal pipe laser cutting machine.
Application
YAG laser cutting machine has been widely used in different kinds of manufacturing and processing lines: metal billboard, metal advertising letter, sheet metal structure, high-low voltage electric cabinet, textile machinery, kitchenware, metal artwork, metal parts, spectacle frame, etc, which have brought customers a high ratio of interest.
Applicable materials
Stainless steel, carbon steel, alloy steel, spring steel, copper sheet, aluminum sheet, gold, silver, titanium sheet and pipe.
Technical Parameter
Model: |
TQL-LCY620-GC4115 |
TQL-LCY620-GC3015 |
TQL-LCY620-GC2513 |
Max. output power: |
620W |
||
Laser wavelength: |
1064nm |
||
Pulse frequency: |
1--300HZ |
||
Min. linewidth: |
0.15mm |
||
Processing scale(length×width): |
4100mmx1500mm |
3000mm×1500mm |
2500mmx1300mm |
Sheet metal cutting thickness: |
0.1mm-8mm |
||
metal tube/pipe cutting diameter: |
10-800mm |
||
Max. length of the pipes |
According to customers' requirements |
||
Pipe cutting thickness: |
0.1mm-8mm |
||
Electrical source: |
380V/50HZ/100A |
||
X,Y,Z axis geometric positioning accuracy: |
≤±0.08mm/1000mm |
||
X,Y,Z axis re-orientation accuracy: |
≤±0.04mm |
||
Cooling mode: |
7P water cooling |
||
Max. cutting speed: |
4000mm/s |
||
