Specifications
>Marks:ZOV/VDR/CNR/CB/TVR>Diameter:25mm
>Tolerance:10%
>Volts:200V
>Materials:zinc oxide
I:Product features of varistors:
A: wide voltage range
B: high current capacity
C: fast response time
II: Product applications: overvoltage protection for:
A: semiconductor devices
B: household appliances surge
C: communication& power facilities surge
D: measuring controlling instruments
E: action surge of ralay & solenoid valve
III:Dimensions of varistors
Models |
Dmax |
Tmax |
Lmin |
C |
H |
d±0.05 |
Fmax |
05D |
7.5 |
7.0 |
25 |
5 |
9 |
0.56 |
4 |
07D |
9.5 |
7.0 |
25 |
5 |
9 |
0.7 |
4 |
10D |
14 |
9.5 |
25 |
7.5 |
9 |
0.7 |
4 |
14D |
17.5 |
12.0 |
25 |
7.5 |
9 |
0.7 |
4 |
20D |
24 |
14.0 |
25 |
10 |
9 |
1.0 |
4 |
25D |
30 |
14.0 |
25 |
10 |
9 |
1.0 |
4 |
32D |
36 |
14.0 |
25 |
10 |
9 |
1.0 |
4 |
IV: Specifications of 25D type varistor
Number |
Volt |
maximum continuous voltage |
maximum continuous voltage |
maximum peak current |
Maximum limit current |
Maximum limit voltage |
capacitance |
|
(V) |
AC(V) |
DC(V) |
(A) |
IP(A) |
(V) |
(PF) |
25D470K |
47 |
30 |
38 |
1250 |
20 |
93 |
10000 |
25D560K |
56 |
35 |
45 |
1250 |
20 |
110 |
8000 |
25D680K |
68 |
40 |
56 |
1250 |
20 |
135 |
7000 |
25D820K |
82 |
50 |
65 |
10000 |
100 |
135 |
6000 |
25D101K |
100 |
60 |
85 |
10000 |
100 |
165 |
5000 |
25D121K |
120 |
75 |
100 |
10000 |
100 |
200 |
4000 |
25D151K |
150 |
95 |
125 |
10000 |
100 |
250 |
3000 |
25D181K |
180 |
115 |
150 |
10000 |
100 |
300 |
2700 |
25D201K |
200 |
130 |
170 |
10000 |
100 |
340 |
2400 |
25D221K |
220 |
140 |
180 |
10000 |
100 |
360 |
2200 |
25D241K |
240 |
150 |
200 |
10000 |
100 |
395 |
2000 |
25D271K |
270 |
175 |
225 |
10000 |
100 |
455 |
1700 |
25D301K |
300 |
195 |
250 |
10000 |
100 |
505 |
1600 |
25D331K |
330 |
215 |
275 |
10000 |
100 |
555 |
1500 |
25D361K |
360 |
230 |
300 |
10000 |
100 |
595 |
1400 |
25D391K |
390 |
250 |
320 |
10000 |
100 |
650 |
1200 |
25D431K |
430 |
275 |
350 |
10000 |
100 |
710 |
1100 |
25D471K |
470 |
300 |
385 |
10000 |
100 |
775 |
1100 |
25D511K |
510 |
320 |
410 |
10000 |
100 |
845 |
1100 |
25D561K |
560 |
350 |
455 |
10000 |
100 |
925 |
1100 |
25D621K |
620 |
385 |
505 |
10000 |
100 |
1025 |
1100 |
25D681K |
680 |
420 |
560 |
10000 |
100 |
1120 |
1000 |
25D751K |
750 |
460 |
615 |
10000 |
100 |
1240 |
1000 |
25D821K |
820 |
510 |
670 |
10000 |
100 |
1355 |
1000 |
25D911K |
911 |
550 |
745 |
10000 |
100 |
1500 |
900 |
25D102K |
1000 |
625 |
825 |
10000 |
100 |
1650 |
800 |
25D112K |
1100 |
680 |
895 |
10000 |
100 |
1815 |
700 |
