Functional Computer Thermal Cutting Bag-making Machine

Specifications

1. Hot Cutting Bag-making Machine
2,Suitable for plastic films such as BOPP,OPP and PE.
3.Sock bag,towel bag, bread bag



Functional Computer Thermal Cutting Bag-making Machine





1.The  whole machine adopts microcomputer control and material-pulling by stepping motor.(Servomotor control system can be selected and equiped).

2.Arbitrary  fixed-length,accurte and stable step photoelectric tracking, stopping  automatically when the label is lost.

3.Automatic and synchronous  two-side tape gluding ,automatic punching.

4.Heat-sealing decorative border,automatic constant temperature, firm and smooth sealing.







Model	RDL-700	RDL-800	RDL-900	RDL-1000
Max.Width of Base Material	700mm	800mm	900mm	1000mm
Max.Cutting Length	50-700mm	50-700mm	50-700mm	50-700mm
Max.Bag-making Width	680mm	780mm	880mm	980mm
Production Capacity	40-140pcs/min	40-140pcs/min	40-140pcs/min	40-140pcs/min
Total Power	3.6 kw	3.8 kw	4.5 kw	4.7 kw
Weight of Machine	900 kg	1000 kg	1100 kg	1200 kg
Overall Dimensions	3500x1100x1800mm	3500x1200x1800mm	3500x1300x1800mm	3500x1400x1800mm
