HG1290 -- the Cheapest Laser Cutting Machine Manufacturer in Shanghai, China

Name: HG1290 -- the Cheapest Laser Cutting Machine Manufacturer in Shanghai, China
Brand: HighGoo
SKU: 116530885

US$ 3,790 - 4,000 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

CO2

Applicable Material:

Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Shanghai Lidong Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type CO2

Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Cutting Thickness 0-20 MM (depends on different materials)

Cutting Area 1200*900 mm

Cutting Speed 0-40000 mm/min

CNC or Not Yes

Cooling Mode Water Cooling

Control Software CorelDraw, AutoCAD

Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP

Place of Origin Shanghai, China

Brand Name HighGoo

Model Number HG1290

Certification CE, ISO, GS, SGS, UL, CCC, Other, CE, ISO, GS, SGS, UL, CCC, B.V.

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Professional laser cutting machine factory
2. High quality & good after-sale service, low price
3. CE, FDA, ISO certificate

1. Applicable Materials

Leather, cloth, wool fabric, fur, acrylic, plexiglas, wooden board, plastic, resin and other non-metal materials.

2. Applicable Industry

processing industries of lager-scale engraving and cutting, such as garment, leather, clipping, cutting of template,

package and printing, advertisement decoration, building upholster, art gift, computer embroidery, paper product, acylic product ,

middle density board ect. Non-metal sheet precision cutting and other industries.

3. Technical Parameters

Laser power :	80W (optional)
Laser type:	Hermetic CO2 glass tube
Power supply:	AC220 ±100‰ 50 HZ/AC110 ±100‰50 HZ
Working area:	1200 mm x 900 mm
Max moving speed:	1500 mm/s
Worktable:	Honey comb worktable / aluminium knife /steel nail (optional)
Locating precision:	<0.01mm
Min shaping character:	Character:3x3 mm, letter:2x2 mm
Operating temperature:	5°c - 35°c
Resolution ratio:	less than 4500 dpi
Control configuration:	DSP
Data transfer interface:	USB (offline)
System environment:	Windows 2000 / Windows XP / Vista/Win 7
Cooling way:	Water cooling and protection system
Graphic format supported:	The file which is CorelDraw, Photoshop, AutoCAD can identify
Compatible software	CorelDraw, AutoCAD
Cutting thickness	0-20 mm (depends on different material)
Color separation	Separation of cutting up to 256 colors
Sloping engraving	Yes, slope can be designed discretionarily
Cuts off the water supply the protection	YES
Machine dimention	1770 * 1200 * 1150 (mm)
Weight	268 kgs
Packing	Plywood case
Optional Parts	High-grade cooling system imported focus lens double-head cylinder rotary attachment irregular rotary attachment
