U Type Super Quality Silicon Carbide Heating Elements(1600C)

FOB Price

US$ 1 - 80 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Kejia		Model Number	High temperature U type silicon carbide heating elements(1600C)
Place of Origin	Henan, China

1.Silicon carbide heating element
2. diameter :8-55mm
3. length:100-4000mm
4. temperature:600-1600C
5. any heating eleme

Silicon carbide heating element

1. SiC heating element of high quality

2. we make ROD, U, W, H, SPIRAL and DOUBLE-SPIRAL types according to your requirement

3.Diameter 8mm to 55mm elements can be made according to your requirements.

4. SiC heating elements is a non-metal electric heating element made from SiC

as its main raw materials.

5.It has some specific properties, such as low expansion coefficient, little deformation,

stable chemical property, long service life, easy installation and maintenance, etc.

6.SiC heating elements can usually make use for furnace which temperature from 600-1600.

7. It can be directly used in the air atmosphere without any protection atmosphere.

8. It is extensively used in the fields of metallurgy, ceramics, glass, machinery,

analysis test, semiconductor, science & research and so on.

physical properties of elements

specific gravity	2.6~2.8g/cm3	Bend strength	>300kg

Hardness	>9MOH’S	Tensile strength	>150Kg.cm3

Porosity rate	<30%	Radiancy	0.85
