1200CF Crucible Melting Furnace With PID Automatic Control

Name: 1200CF Crucible Melting Furnace With PID Automatic Control
Brand: KeJia
SKU: 116516997
Availability: InStock

US$ 1,201 - 6,700 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Resistance Furnace

Usage:

Heat Treatment Furnace

Zhengzhou Kejia Furnace Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhengzhou Tianjin etc

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Resistance Furnace

Usage Heat Treatment Furnace

Place of Origin Henan, China

Brand Name KeJia

Model Number KJ-1200CF Crucible Melting Furnace with PID automatic control

Specifications

1. KJ-1200CF Crucible Melting Furnace,
2. Heated by Resistance wire,
3. Working temp., 100-1250C.

Model: KJ-1200CF Crucible Melting Furnace with PID automatic control

Size: 240x220mm (9.5"x8.6"), (DxH).

Features:

1. has a large chamber (9.5"d x 8.6"H) and it is designed for sintering ceramic parts and component in Lab and Hobby Shop.

2. has a unique ceramic fiber insulation around the chamber to provide excellent uniformity and energy efficiency.

3. The heating element is embedded in the insulation for maximum heat transfer to the chamber. Max. temperature can reach 1250°C.

4. Power control with 30 segments programmable.

5. All accessories are included for immediate use,

1) One piece of refractory disk, which can be put on bottom of furnace to protect furnace liner from wearing out.

2) Three pieces of refractory supports, which can be put on top of the disk and bottom of the crucible to adjusting crucible height.

3) One high temperature gloves using can be used < 900°C.

Descriptions

Chamber Size (DxH)	240x220mm (9.5"x8.6")
Working Temperature	100-1250°C
Temperature Control	30 steps programmable and PID automatic control
Temperature Rise Time	1. <60 min. to 1000°C, 2. 1000oC-1200°C, heating rate <5°C/min.).
Max. Heating rate	40°C/min.
Temperature Accuracy	+/-1°C
Uniformity	+/-2°C
Heating Element	Resistance wire
Working Voltage	AC 220V, Single Phase, 60/50 Hz (or according to your requirement)
Max. Power	3 KW
Outside Size	510 x 435 x 425mm
Net Weight	30 Kg
Gross Weight	55 Kg
