HORIZONTAL WRAPPING MACHINE,FILM WRAPPING MACHINE,PACKING MACHINE

Specifications

HORIZONTAL WRAPPING MACHINE
FILM WRAPPING MACHINE
packaging machie
RING INSIDE DIAMETER IS 0-450MM

YK-S450 Horizontal Stretch Wrapping machine,STRETCH FILM WRAPPER,

PACKING MACHINE



CONTROL SYSTEM



Automatically sense the operation position of the goods and the material position through four induction switch in the process.



 PLC control

The machine can match with production line.



Description:



The principle of  horizontal stretch wrapper is packing materials through rotating arm system around uniform forward goods to do rotational motion, and through the tensile agencies regulate the tension of the packing materials at the same time, and make the objects tighten so that a spiral of packaging form on the surface of the objects.



The packing has elegant appearance and can protect the products from dust and moisture.

We are now improving the packing quality of the products and increasing the market competitive power.





Technical      Parameter



Ring inside dia.	0-450mm
Ring rotation speed	0-30 rpm(max)
Wrap material	film/ complex punched tape
Max wrapping size	Length3000mm, Width 400mm,Height 300mm
Air consumption	100ml/min
Power	380v 2.5kw,50-60HZ
Packing Ability:	30 pieces/HR
Machine weight:	650kg
Shape dimension:	3500mm×1400mm×1600mm
Control system	PLC control ,with self induction system , layers and speed adjustable
Special machine could be made (Optional automatic device to convey the film & cut the film)
