Help CenterYK-1200S Full-Automatic Door Stretch Film Wrapping Machine
Related Products
-
YK-S450 Horizontal Flow Stretch Wrapping MchineUS$ 1 - 2MOQ: 1 Set -
YK-HS800 High Speed and Reputations Economic Cost Orbital/Horizontal Stretch Wrapper With Stretch FilmUS$ 1 - 2MOQ: 1 Set
-
YK-450S Fully Automatic Iron Bar Horizontal Flow Wrapping MachineUS$ 1 - 2MOQ: 1 Set
-
YKS-450 Horizontal Stretch Film Pallet Wrapping MachineUS$ 12,500 - 15,000MOQ: 1 Piece
-
Horizontal Orbital Stretch Wrapping Machine,conveyorized Pallet Wrapping Machine, WrappingUS$ 3,350 - 3,750MOQ: 5 Sets
YK Series Stretch wrapping machines are used to wrap stretch film around a loaded pallet.
Film provides extra support while the products are being transported & storaged to protect them
from tip, spill or from being damaged. Additionally , wrapped loads can easily be separated and
identified.
Horizontal wrapper wraps products that won`t fit on a turntable, require banding, compression or
extra packing for shipment. It has a proven record of success in many industries such as profiled
product, tubular product and plank stuff etc. We offers a wide variety of options to meet your specific
requirements. Each applications is evaluated to provide the right solution to your needs
2nd,Technical Parameter:
Ring inside dia. |
1200mm |
Ring Cycle speed |
0-30 rpm (max) |
Max wrapping size |
Length 6000mm- 10 meter, Width 1800 mm,Height 200mm Special machine could be made |
Max wrapping weight |
500 kg |
Pneumatic system |
0.4-0.6Mpa ,20NL/min |
Power |
380v,3kw,50-60HZ |
Packing Ability: |
30 pieces/HR |
Rotary Ability: |
0~30m/min, Rotating speed adjustable,controlled by frequency changer |
Power |
3KW(without conveyor system) |
Material: | |
Packing Material |
Compound paper tape/knit tape/anti-rust tape/waterproof tape/stretch film |
Film/tape width |
70mm-300mm, |
Coil external diameter |
φ260mm |
Coil internal diameter., |
φ76.2mm |
Thickness |
0.035mm~0.050mm |
Conveying System : | |
Conveyor height |
760mm,height should be over 700mm |
Conveyor Width |
450 mm + |
Roller Diameter |
Φ76mm,distance 114mm |
Conveying Speed |
0~13meter/min,adjustable |
| |
Thanks for you inquiry our door wrapping machine here,please do not hesitate and send me a inquiry right now.
