ULTRA ISOLATION TRANSFORMER 1000 KVA
- 100 Unit / Units per Month
- mumbai
- T/T L/C D/P D/A
- Acrel ABAT-S battery-powered module device for Battery Monitoring System less than 13mA (1.2V&2V) or 7mA(6V&12V)quiescent
- Acrel ABAT-S battery analyzer monitoring system On-line monitoring of the voltage internal resistance of each backup battery
- Acrel ABAT-C Battery Monitoring Module Lead Battery Charge Discharge output 4-20mA
- Acrel ABAT Battery Monitoring System used for Base Station for 2V/6V/12V Lead Acid Batteries with RS485 communication
- Acrel ABAT-S battery analyzer monitoring system Interfaces with most UPS controller
- Acrel ABAT-S Lead-acid module device per battery to monitor internal resistance voltage and temperature
Product Details
Place of Origin: | Gujarat, India | Brand Name: | PEC | Model Number: | 1000 KVA |
Product Description
Specifications
ULTRA ISOLATION TRANSFORMER 1000 KVA
ULTRA ISOLATION TRANSFORMER
RANGE: 5 KVA TO 2000 KVA
Ultra / Super Isolation Transformers are effective for Isolating sensitive equipment’s from line voltage transients, spikes & DC Leakage etc. They are specially designed for sensitive critical equipment’s like computers & peripherals, medical instrumentation, digital communication telemetry system, CNC Machines etc. and stopping such disturbances generated by the noisy equipment load from being injected into the power line.
Multiple shielding techniques employed reduce the inter winding capacitance to below 0.005 Pico farad and increases DC Isolation to over 1000 Mega ohms.
Technically, any transformers that have no direct current path between it’s primary & secondary windings provides Isolation. Other commonly used, transformers even if they have separate primary & secondary winding are intended to convert the input voltage to a more useful level & do very little to attenuate the passage of noise or transients from primary to secondary. Even though both are separately wound transformers, they are substantially different w.r.t. construction, specification & performance characteristics.
Technical Specification | ||
Input | Output | Rating Available |
415V AC 3 PH | 415V AC 3 PH | 5 KVA to 2000 KVA |
or as per requirement | Both Oil & Dry Type | |
System Connections : Delta / Star (as per requirement) | ||
Ratios : 1:1 (as per requirement) | ||
Regulation : 5% | ||
Power Factor : 0.75 lead to 0.75 Lag | ||
Insulation Resistance : Better than 5 mega ohm | ||
Coupling Capacitance : 0.01 PF for 100 Db | ||
Leakage Current : Less than 20 Micro Amps | ||
Type of Execution : Closed Type | ||
Operating Temperature : o C to 45 c | ||
Type of Cooling : ONAN /Natural Air / Forced Air |
