H01N2-D/-E, Welding Cable, 100 V, Flexible Cu/Cr (EN 50525-2-81)
US$ 0.5 - 9
MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Boan or OEM
Model Number:
H01n2-D/-E
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Shd-Gc Mining Cable Cu/Epr/CPE 3/C 5kv ICEA S-75-381US$ 1 - 5MOQ: 500 Inches -
H05RR-F, Rubber Cable, 300/500 V, Flexible Cu/Epr/Cr (BS 7919/VDE 0282-4)US$ 0.5 - 5MOQ: 500 Meters
-
H07BQ-F, Rubber Cable, 450/750 V, Flexible Cu/EPR/TMPU (HD22.10)US$ 0.5 - 11MOQ: 500 Meters
-
Arc-Welding Cable, Welding Machine Cable, Flexible CU/EPR, 600 V (ICEA S-75-381/NEMA WC 58/CAN/CSA C22.2 No. 96/UL 1581)US$ 1 - 7MOQ: 500 Meters
-
H05RN-F, Rubber Cable, 300/500 V, Flexible CU/EPR/PCP (BS 7919/VDE 0282-4)US$ 0.5 - 10MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
Boan or OEM
Model Number
H01n2-D/-E
Insulation Material
Rubber
Type
Low Voltage
Application
Other, Welding
Conductor Material
Copper
Jacket
Other
Product Description
H01N2-D/-E, Welding Cable, 100 V, Flexible CU/CR (EN 50525-2-81)
conductor material: bare copper
sheathing material: rubber (CR) EM5
flame retardant: VDE 0482-332-1-2/IEC 60332-1
oil resistant: EN 60811-2-1
maximum temperature at
conductor:
85 °C
max. operating temperature,
fixed:
-20 - +85 °C
nominal voltage Uo: 100 V
nominal voltage U: 100 V
test voltage: 1 kV
Application: In dry, damp and wet rooms as welding cable for machine or hand operation.
| Specification | D.C. Resistance at 20ºC | Bending Radius | Outer Diameter | Conducotr Weight | Total Weight |
| [Ω/km] | [mm] | [mm] | [kg/km] | [kg/km] | |
| H01N2-D | |||||
| H01N2-D 01X16 SW | 1,16 | 46 | 9,2 | 154 | 220 |
| H01N2-D 01X25 SW | 0,758 | 65 | 10,5 | 240 | 300 |
| H01N2-D 01X35 SW | 0,563 | 73 | 12,1 | 336 | 410 |
| H01N2-D 01X50 SW | 0,379 | 85 | 13,5 | 480 | 560 |
| H01N2-D 01X70 SW | 0,263 | 98 | 16,2 | 672 | 770 |
| H01N2-D 01X95 SW | 0,198 | 110 | 18,5 | 912 | 1050 |
| H01N2-D 01X120 SW | 0,155 | 120 | 20,1 | 1152 | 1290 |
| H01N2-D 01X150 SW | 0,129 | 135 | 22,5 | 1440 | 1590 |
| H01N2-D 01X185 SW | 0,106 | 146 | 24,4 | 1776 | 1916 |
| H01N2-D 01X240 SW | 0,0801 | 177 | 29,5 | 2304 | 2540 |
| H01N2-E | |||||
| H01N2-E 01X10 SW | 1,91 | 6,9 | - | 96 | 122 |
| H01N2-E 01X16 SW | 1,21 | 7,9 | - | 154 | 235 |
| H01N2-E 01X25 SW | 0,78 | 9,4 | - | 240 | 282 |
| H01N2-E 01X35 SW | 0,554 | 10,5 | - | 336 | 363 |
| H01N2-E 01X50 SW | 0,386 | 12,8 | - | 480 | 534 |
| H01N2-E 01X70 SW | 0,272 | 14,2 | - | 672 | 716 |
| H01N2-E 01X95 SW | 0,206 | 16,8 | - | 912 | 1012 |
| H01N2-E 01X120 SW | 0,161 | 18,2 | - | 1152 | 1240 |
| H01N2-E 01X150 SW | 0,129 | 19,8 | - | 1440 | 1442 |
| H01N2-E 01X185 SW | 0,106 | 21,2 | - | 1776 | 1867 |
