Home > Products > High Brightness LED Strip > Best quality sample free LED Strip Waterproof RGB Green smd 3528 60 leds LED strip light lighting
Best quality sample free LED Strip Waterproof RGB Green smd 3528 60 leds LED strip light lighting
USD $1 - $10
/ Meter
200 Meters(Min.Order)
- 300000 Meter / Meters per Month
- Shenzhen
- T/T
You May Like
-
WS2812b 5v dream color led strip 2 Years Warranty rgb SK6812 rgbic addressable ws2812b led strip
-
Hot Flexible Led Wall Washer Light DC24V RGBIC Outdoor IP65 Waterproof Led Lights Wall Washer For Architectural Lighting
-
RGB LED Strip Addressable Light 5V 5050 RGB SMD Individually 48 pixels/m RGB Digital APA102 SK9822 30 60 96 144 LEDs/m
-
Addressable Silicon Neon Strip 6*13 mm SK6812MINI 3535 RGBIC Waterproof Digital rgb LED Neon Flex Strip Light
-
DC36V RGBW UCS2904 5050 Digital LED Light Strip 2904 RGBW 30M Pixel Smart control Led Strip Lighting
-
30m 5050SMD Light Source Flexible High Voltage 36V WS2811 Constant Current RGB LED Strip Light
Product Details
| LED Light Source: | Epistar SMD 3528 LED | Type: | Flex LED Strips | Input Voltage(V): | DC 12V LED Rope Light |
| Lamp Power: | 4.8W Per meter LED Tape Light | Lamp Luminous Flux(lm): | 7-8lm Per LED | Color Temperature(CCT): | 520-530nm |
| Working Temperature(℃): | -40, 50 | Working Lifetime(Hour): | 30000 | Lamp Body Material: | Copper |
| Certification: | CE | Emitting Color: | Red | Place of Origin: | Guangdong, China |
| Brand Name: | Hanron | Model Number: | HR00-A12DG60PA |
Product Description
Best quality sample free LED Strip Waterproof RGB Green smd 3528 60 leds LED strip light lighting
SMD3528 LED Strip Specification:
| Item NO. | HR00-A12DG60PA |
| Voltage | 12V |
| Power | 4.8W/Meter |
| Led number | 60leds/Meter |
| CCT | 520-530nm |
| Color | Green |
| IP Grade | IP65 Silicone Waterproof |
| Certificate | CE&RoHS |
| Warranty | 5Year |
Features:
TOP SMD3528 chip, high brightness, wide beam angle, low decay.
Low power consumption, long life span, free maintenance
Easy to install for any bending
Storage temperature:-50℃ - 60℃
Working temperature: -40℃ - 50℃
Certification: CE & RoHs
Application:
- Cove lighting
- Backlight or edge lighting for signage
- Path and contour marking
- Architectural lights for canopy, corridor, window, archway
- Special light effect for art gallery and glass-made items
- Path and contour marking
- DIY lights for home use
Parameter
| Item NO. | Description | Color | Wave Length/C. T. | Luminous Flux/M | Beam | Protect Level | Size |
| Angle | (mm) | ||||||
| HR00-A12AWW60PA | Non-Waterproof SMD3528 SMD3528 | WW | 2800-3200K | 450LM±10% | 120° | IP20 | 5000*8*2mm |
| HR00-A12ANW60PA | NW | 4000-4500K | 450LM±10% | ||||
| HR00-A12AW60PA | W | 5500-6500K | 450LM±10% | ||||
| HR00-A12AR60PA | Red | 620-630nm | 136LM±10% | ||||
| HR00-A12AY60PA | Yellow | 585-595nm | 136LM±10% | ||||
| HR00-A12AB60PA | Blue | 465-475nm | 84LM±10% | ||||
| HR00-A12AG60PA | Green | 520-530nm | 242LM±10% | ||||
| HR00-A12DWW60PA | Silicone Waterproof SMD3528 60LED/M | WW | 2800-3200K | 450LM±10% | 120° | IP65 | 5000*8*2.2mm |
| HR00-A12DNW60PA | NW | 4000-4500K | 450LM±10% | ||||
| HR00-A12DW60PA | W | 5500-6500K | 450LM±10% | ||||
| HR00-A12DR60PA | Red | 620-630nm | 136LM±10% | ||||
| HR00-A12DY60PA | Yellow | 585-595nm | 136LM±10% | ||||
| HR00-A12DB60PA | Blue | 465-475nm | 84LM±10% | ||||
| HR00-A12DG60PA | Green | 520-530nm | 242LM±10% | ||||
| HR00-A12EWW60PA | Silicone Tube Waterproof SMD3528 Waterproof 60LED/M | WW | 2800-3200K | 450LM±10% | 120° | IP67 | 5000*8*3.8mm |
| HR00-A12ENW60PA | NW | 4000-4500K | 450LM±10% | ||||
| HR00-A12EW60PA | W | 5500-6500K | 450LM±10% | ||||
| HR00-A12ER60PA | Red | 620-630nm | 136LM±10% | ||||
| HR00-A12EY60PA | Yellow | 585-595nm | 136LM±10% | ||||
| HR00-A12EB60PA | Blue | 465-475nm | 84LM±10% | ||||
| HR00-A12EG60PA | Green | 520-530nm | 242LM±10% | ||||
| HR00-A12FWW60PA | Glue Filling Waterproof SMD3528 60LED/M | WW | 2800-3200K | 450LM±10% | 120° | IP68 | 5000*8*3.8mm |
| HR00-A12FNW60PA | NW | 4000-4500K | 450LM±10% | ||||
| HR00-A12FW60PA | W | 5500-6500K | 450LM±10% | ||||
| HR00-A12FR60PA | Red | 620-630nm | 136LM±10% | ||||
| HR00-A12FY60PA | Yellow | 585-595nm | 136LM±10% | ||||
| HR00-A12FB60PA | Blue | 465-475nm | 84LM±10% | ||||
| HR00-A12FG60PA | Green | 520-530nm | 242LM±10% |
Dimension
Connect Drawing
Installation
1. The black of strip stick with 3M tape. Only need to rive the face paper on 3M tape when use.
2. Stick the strip anywhere 3M tape easy to fix.
3. When install strips, it can be cut at the marks of scissors according to length.
4. Fix the strips with screw of clip lock.
Certificate
Factory Tour 1
Factory Tour 2
Our Advantage
Quality Control
Contact Us
- Shenzhen Hanron Lighting Co., Limited
- Contact nameIvan Huang
- Phone86-0755-23595836
- AddressBuilding 1, Hongfa Jiateli High-Tech Park,Shiyan Town, Baoan District Shenzhen,Guangdong
