Rice Husk Rotary Dryer Machine With Patent

Rice Husk Rotary Dryer Machine With Patent photo-1
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
sanjin machine
Model Number:
T400
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name sanjin machine
Model Number T400

Specifications

rice husk rotary dryer machine with patent
1.easy operation
2.high efficiency
3.perfect drying effect

rice husk rotary dryer machine  with patent



1.Working Principle

Patent Number:200520031211.8

Rice husk rotary dryer is to dry the wet materials with the humidity of 50% through rotation and extract from the end of the roller. It can reach drying one time.

This dryer applies to material such as rice shell, saw dust, ground wood chip, tree branch and wood bits, etc.This dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.



2.Structure Features

*Adopt rolling drum feeding method.  Drying is uniform and the motor power is small.

* Heat supply is external indirect heating method and avoid raw materials burning in high temperature.

* Equipped special parts in the tail of rotary dryer, only the material that to reach the drying standard can be drove out by blower, ensuring the drying purpose.

* The machine attached dust catcher equipment in discharge hole so as to separate material and moisture, and reduce the dust in workshop at the same time.





3.Technical Data

Type

Diameter of

raw material(mm)

Length of raw material(mm)

Capacity(kg/h)

Power(kw)

Dimension(m)

Roller

Blower

T400

<=5

<=6

500-800

5.5

4

15.6*1.2*3.3

T620

<=20

<=20

800-1200

5.5

4

15.6*1.2*3.3

T950

<=20

<=20

1200-1500

7.5

7.5

18.3*1.3*5

rice husk rotary dryer machine with patent

 rice husk rotary dryer machine with patent
