Specifications
soybean oil press machine price:1. High oil rate;
2. Widely used;
3. High qualty;
4.Labour saving.
Multi-function automatic soybean oil press machine price
Range of application:
Our oil press machine used in peanut ,soybean,sunflower,vegetable seeds,coconut,etc and all kinds of plants for edible oil.
Main features:
1. High oil yielding, low oil residual in the cake: The oil left in cake is less than 6%. The cake thickness can be adjusted once the machine stops running;
2. Small-land using:only10-20 squaremeters workshop can make production.
3. Pure oil quality: : machine surface is made of chrome plated stainless steel, in line with food hygiene standards; Also with two vacuum oil filters, the residual can be removed from by simply filtering;
4. Other advantages: high efficiency, energy and labor saving, easy operation.
Advantage:
1.Saving labor: it can save 60% labor for equal output and 40% labor cost per day for one or two people are able to make production.
2.Widely-used: it can be used to completely press more than 20 kinds of oil crops, such as peanuts, sesame, vegetable seeds, soybean, oil sunflower and flax by third levels for one time.
3.Pure oil quality: the vacuum oil filtering is used to remove residue so as to ensure the pure oil quality and meet the standard of health quarantine .
4. Small land-using: an area of 10-20 m2 workshop can meet the need of production.
5. Using vacuum filter, it is able to simply filter the crude oil after pressing
6. It is able to save labour, about 60% . One or two person is for per machine
7. Protection the environment, comparing with the traditional oil press machine,
it is about to meet the standard of green environment .
8. Low investment, get more profit.
Operating principle:
1.When oil press is on work, material enters the extruding chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed.
2.Under hightemperature condition in the chamber, there is quite strong friction among press screw, chamber and the oil materials.
3.On the other hand, root diameter of the pressing screw carries larger from one end to the other.
4.Hence when rotating, the thread not only pushes particles moving forwards but also turns them outwards as well.
5.Meanwhile, particles adjacent the screw will rotate along with screw’s rotating, causing every particle inside the chamber to possess different speed.
6.Therefore, relative movement among particles creates neat which is necessary during manufacturing because of helping protein change property, damage colloid, increase plasticity, decrease oil’s elasticity, resulting in high oil.
Technical specification:
Model |
Screw D.I. |
Screw Speed |
Motor |
Heater |
Capacity |
Weight |
Size |
DS-80 |
80mm |
50r/min |
Y132M-4 |
2KW |
50-80 |
500kg |
1500*1000*1800 |
DS-100 |
100mm |
40r/min |
Y132M-4 |
2KW |
80-150 |
700kg |
1800*1000*1900 |
DS-120 |
120mm |
36r/min |
Y132M-4 |
3KW |
100-200 |
1000kg |
2000*1200*2000 |
DS-130 |
130mm |
36r/min |
Y132M-4 15KW |
3kw |
200-400kg/h |
1300kg |
2100*1200*2000 |
DS-165 |
165mm |
35r/min |
Y132M-4 22KW |
3kw |
450-800kg/h |
1700kg |
2200*1500*2100 |
Relative pictures:
