3-50 M3/min Capacity 0.8-1.3Mpa Working Pressure Portable Screw Air Compressor

3-50 M3/min Capacity 0.8-1.3Mpa Working Pressure Portable Screw Air Compressor thumbnail-1
3-50 M3/min Capacity 0.8-1.3Mpa Working Pressure Portable Screw Air Compressor photo-1
US$ 10,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw
Configuration:
Portable
Contact Supplier Request Quote Chat Now
Zhengzhou Zoonyee Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Screw
Configuration Portable
Power Source Gasoline
Lubrication Style Lubricated
Mute Yes
Place of Origin Henan, China
Brand Name ZOONYEE
Model Number LGCY-7.5/7
Voltage standard
Dimension(L*W*H) 3900*1920*1700mm
Weight 1850 kg
Certification CE
Warranty 15 months
After-sales Service Provided Engineers available to service machinery overseas

3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor







Product Description



Introduction of Portable screw Air Compressor

1)  “larger rotor,slow speed of revolution”design,full-spectrum screw end direct drive; dedicated masterpiece of the world’s top expert in air compressor –Doctor Tangyan.Rotor profile performance have reached international advanced level.



2)   the end ’s compression chamber ,with the front bearing designed in an organic whole, the structure is more simple ,more compact .the host oil embedded designed.



3)  the life of bearing is more than 1000,000 hours



4)  air intake ,exhaust vent design according to different operating condition ,ensure the compressor end suitable to different operating condition with excellent performance.



5)  high precision screw rotor, relized perfect unify in excellent performance and realiablity.



6)  high efficiency, low noise, low vibration, the screw end performance have reached international advanced level.



Specification of Portable screw Air Compressor





Modle

Capacity

(m3/min)

Working pressure (Mpa)

Motor power

(kw)

Weight

(kg)

Demension(L*W*H)

(mm)

LG-3/8G

3

0.8

18.5

650

1080*880*1415

LG-2.7/10

2.7

1.0

LG-2.3/13

2.3

1.3

LG-3.6/8 G

3.6

0.8

22

650

1420*850*1110

LG-3.6/8

3.6

0.8

700

1080*880*1415

LG-3.2/10

3.2

1.0

LG-2.7/13

2.7

1.3

LG-5/8

5

0.8

30

900

1300*1100*1650

LG-4.5/10

4.5

1.0

LG-3.7/13

3.7

1.3

LG-6.2/8G

6

0.8

37

900

1630*910*1220

LG-5.6/10

5.6

1.0

1000

1300*1100*1650

LG-4.8/13

4.8

1.3

LGB-6.0/8

6

0.8

LGB-5.6/8G

5.6

1.0

LGB-4.8/13

4.8

1.3

LG-7.0/8G

7.0

0.8

45

1000

1778*1000*1300

LG-7.5/8

7.5

0.8

1100

1300*1100*1650

LG-6.9/10

6.9

1.0

LG-5.6/13

5.6

1.3

LG-10/8G

10

0.8

55

1400

1950*1160*1550

LG-8.7/10

8.7

1.0

1620*1230*1670

LG-7.5/13

7.5

1.3

1250

1500*1250*1566

LGB-9.3/8

9.3

0.8

LGB-8.5/10

8.5

1.0

LGB-7/13

7

1.3

LG-13/8G

13

0.8

75

1900

2440*1160*1620

LG-11.6/10G

11.6

1.0

LG-9.3/13G

9.3

1.3

LGB-13/8

13

0.8

1600

1580*1320*1646

LGB-11/10

11

1.0

LGB-9.3/13

9.3

1.3

LG-16/8G

16

0.8

90

2100

2560*1300*1620

LG-13.5/10G

13.5

1.0

LG-11.6/13G

11.6

1.3

LG-20/8G

20

0.8

110

2800

2760*1340*1710

LG-16/10G

16

1.0

LG-13.5/13G

13.5

1.3

LG-22/8G

22

0.8

132

2900

2760*1340*1710

LG-20/10G

20

1.0

LG-16/13G

16

1.3

LG-27/8G

27

0.8

160

3600

2860*1510*1810

LG-23/10G

23

1.0

LG-20/13G

20

1.3

LG-30/8G

30

0.8

185

4500

3400*2100*2100

LG-21/13G

21

1.3

3700

2860*1510*1810

LG-30/8GB

30

0.8

200

4500

3400*2100*2100

LG-22/13GB

22

1.3

3700

2860*1510*1810

LG-35/8G

35

0.8

4500

3400*2100*2100

LG-30/10G

30

1.0

LG-27/13G

27

1.3

LG-40/8G

40

0.8

220

5850

3700*2200*2200

LG-40/8GA

40

0.8

LG-35/10G

35

1.0

250

5950

3700*2200*2200

LG-40/8G

40

0.8

LG-46/8G

46

0.8

6000

LG-40/10G

40

1.0

LG-33/13G

33

1.3

LG-50/8G

50

0.8

280

7000

4200*2200*2210






Photos:

3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor

3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor3-50 m3/min capacity 0.8-1.3Mpa working pressure portable screw air compressor
