Specifications
1.automatic feeding2.low dust
3.strong drying strength
Charcoal making sawdust dryer machine
Product item : Charcoal making sawdust dryer machine also called pipeline type dry machine, adopting twice circulate heating system, is our newly developed advanced drying equipments, and show the features of automatic feeding, high hot airflow speed, fully mixing of airflow and materials, big drying strength, lower dust and bigger drying capacity. Moisture in the raw mateials of less than 40% can be drying one time to meet the requirement for coal bar production, which greatly reduced the labor intensity compared with commonly used drier.
Material to dry:
Particular material as rice shell, saw dust, and ground wood chip, tree branch, wood bits, etc,.(Diameter is less than 3mm; Length, 5mm)
Operating rules for drying machine
1. After installation, start the blower, check the direction it runs and see if the suction at the material inlet is normal.
2. Tie up a bag whose both ends are open around the outlet of the dust catcher.
3.Feed the material to be dried to the hopper. Remove large grain in the material before drying, which will benefit drying speed.
4. Put fuel into the furnace and light it, start the blower. When the air temprature at the outlet of the blower get to 100°C, begin feeding and drying.
5.Large piece of the material at dregs-outlet must be removed, which is favourable to feeding.
Model |
QLH-300 |
QLH-2 |
QLH-3 |
QLH-4 |
|
Capacity |
180-300kg/h |
200-400kg/h |
400-600kg/h |
500-700kg/h |
800-1000kg/h |
Diameter of materials |
<=5mm |
<=5mm |
<=5mm |
<=5mm |
|
Power |
4kw |
7.5kw |
7.5kw |
18.5kw |
18.5kw |
Moisture of materials |
<=20% |
<=50% |
<=50% |
<=50% |
|
|
Moisture of materials after drying |
<=10% |
<=10% |
<=10% |
<=10% |
|
Weight |
1T |
2.5T |
2.7T |
4T |
4.5T |
