Help CenterDigital t Shirt Direct to Fabric or Textile Multifunction Flatbed Printer
Related Products
-
Industrial High Speed DTG Printer,most Suitable for t Shirt PrinterUS$ 16,000 - 17,500MOQ: 1 Set -
Polar-Jet Direct to Garment 3d t Shirt Printing MachineUS$ 16,000 - 17,500MOQ: 1 Set
-
Best Price and Quality for Textile Printer Quality ChoiceUS$ 16,000 - 17,500MOQ: 1 Set
-
Most of Customers Recommend Vega-Jet DTG Tshirt PrinterUS$ 6,000 - 7,700MOQ: 1 Piece
-
Best Quality of Dtg Printer Polar-Jet Industrial Tshirt PrinterUS$ 14,700 - 15,600MOQ: 1 Piece
Direct to printing dtg printer information as follows:
Focus Polar-Jet digital tshirt printing machine is a newest created Industrial DTG direct to digital flatbed printer. It was built under newest T7000 printing technology, 360nozzle per line, total 3600 nozzle, variable ink droplet technology get a grayscale printing result, Air negative pressure system go with individual keep wet cap station to anti head clog. Match with Wasatch professional Color raster RIP to get a vivid printing result on light and dark underbase. Combine with Focus IPPS control system to get a reliable quality thanks to the top industrial configuration as French Scheider PLC controler, Touch screen, Fuji film 750W AC servo motor, Dual ball screw and THK Linear rail. Compare with Original F2000 Tshirt printer, Focus Polar-Jet is faster, super printing size, industrial made and also costless. Focus Polar-Jet digital tshirt printing machine is the first choice to lead you get the industrial DTG printing.
Specification
| ocus Polar-Jet Industrial DTG Printer | ||
| Print head |
Newest Advanced MicroPiezoPrintHead Variable Size Ink Droplet Technology — Smallest droplet size of 3.5 picoliters |
|
| Printing speed (40*55cm area) | 720*360dpi | 200pcs shirt / Hour |
| 720*720dpi | 160pcs shirt / Hour | |
| 720*1440dpi | 100pcs shirt/ Hour | |
| 1440*1440dpi | 50pcs shirt/ Hour | |
| Color channel setting | Optional choose | |
| Color management | ICC curve | |
| Max. Printing size | 1118mm*500mm | |
| Pallet size | 520*500mm standard shirt pallet*2pcs | |
| Printing Direction | Uidirection / Bidirection | |
| Ink dot jet frequency | 1Hz-2000Hz optional | |
| Carriage drive type | DC servo motor | |
| Table drive type | AC servo motor | |
| Guide type | Linear rail | |
| Ink dot type | 1bits, 2bits, dark, halfton, real time | |
| Fire type type | Rand, fog, wave, 2D | |
| Head maintainance type | Wet-cap system / Auto flash system | |
| Control type | Computer Intelligent & PLC controller | |
| Printing resolution |
720*360dpi / 720*540dpi/ 720*720dpi/ 720*1080dpi 720*1440dpi / 720*2160dpi/ 720*2880dopi |
|
| Color Ink Tank Volume | 700ml cartridge * 4pcs | |
| White ink tank volume | 700ml Cartridge supply | |
| Ink type | DTG ink/ sublimation ink/ reactive ink/ discharge ink/ eco solvent ink/ CTS ink. | |
| Ink process | Filter system+white ink shaking system+white ink circulation system | |
| Printhead Protection | Intelligent Self Protect System | |
| Power | 110-220V 50-60HZ 250W | |
| Printing Interface | USB2.0/ USB3.0 | |
| Operation System | Win2000/ WinXP/.Win7 / Win8 | |
| Working Environment | 50%humidity, 21-29℃ | |
| Printer Size | L1608mm*W1400mm*H1128mm | |
| Shipping Size | L1700mm*W1450mm*H1200mm | |
| Printer N.Weight/G.Weight | 210KG/255KG | |
Catalog download: /download/a4dg665jxhwlbua/Focus_Polar-jet_industrial_DTG_printer_manual.rar
Online video demo: http://youtu.be/44AOUodn0v4
Technical features
1. New revolutionary printing technology
Polar-Jet was built with newest printing technology, Mounted with newest advanced piezzo print head. Variable size ink droplet technology, Smallest drop size 3.5piccolitters to get a grayscale printing result, 720 nozzle per color X 5 color, total 3600 nozzle, Maximum printing resolution 2880*1440dpi.
2. New ink supply system to anti-clog of print head.
Configure with negative air supply system to the damper and print head kit to solve out the head clog problem. Can get a obvious effective for white ink printing especially and high speed printing. The old version model with DX5 print head all are suppy the ink to the print head by syphonage way, so the white ink will be easy to clog as longtime settling. But with the negative pressure system, the ink inside the damper and print head will be absorbed by the negative pressure to keep a certain ink level without change. so it can prevent the ink clog, ink dripping and ink Oblique jet effectively.
3. New designed keep wet cap station
The new designed dtg printer cap station divide each cap for each color line individual, traditional printer all use one cap for all color or half color, so it will cause the ink get mixed inside the cap station during keep wet at night. so the color near white head will be easy to be clogged, so the new cap station is designed specially for prevent the ink mixture and head clog.
4. No chips reset require
Focus invented chips reset system let you forget the problems of reset the ink cartridge chips, chips can not be detected... also 700ml big ink tank can reduce you job of refilling.
5. TCP/IP Ethernet cable interface
Print via TCP/IP Ethernet cable let the data processing faster than traditional USB 2.0/3.0 way
6. Supported by Wasatch professional Image raster RIP software
Wasatch SoftRIP helps users achieve superior color accuracy, high production speed, variable data customization, spot matching and cost savings with direct-to-garment inkjet printers, support ICC revise, ICC maker, Custom ink channel setting. Printing to dark garments has never been easier! With Wasatch's new Auto-Generation features selected, white ink will automatically be printed as an underlay of your image. Use the Wasatch Tracer to create a mask around your image to easily eliminate any image data that you don't want printed. This is ideal for images with background colors that are not a solid fill. This will save on ink consumption and keep the "hand" of your printed shirt light.
7. Intellective PLC control system
Polar-Jet use the intellective French Scheider brand PLC controller to control all motion signal as forward/backward, online/offline to ensure the reliable working.
8. French Schneider brand control panel
The Scheider brand control panel make you opreate the machine easier and Humanity .
9. Mounted with Fuji 750W servo motor
The Fuji brand 750W servo motor was mounted at Polar-jet for drive the flatbed/ pallet backward/forward motion. Strong powerful and the open loop design make sure the flatbed motion with high precision.
10. Automatic media thickness adjustment
Polar-Jet support maximum 80cm media thickness, just input the media thickness number to the control panel.
11. Duall ball screw & linear rail for Z axis motion
Ball screw and linear rail were mounted at both side of the flatbed to guide the top printer move at Z axis with high precision, ensure the printing table water level at any positon to get a equal printing quality.
12. Dual ball screw and linear rial for Y axis motion
Printing table motion precision will effect the printing result directly, especially for print on dark underbase, as the rough motion precision will cause the printing image overlap. Polar-jet mounted with the Japan NSK brand ball screw combine with THk brand rail at both side for
a high motion precision with error less than 0.05mm repeatedly.
13. Easy-changing pallet
Polar-Jet digital tshirt printing machine support dual T-shirt printing pallet with size 40cm*55cm for each and big pallet with maximum printing size100*70CM.
Printing sample
Warranty
1.We provide 13month warranty since the shippin date.
2.We have completely english instruction video and manual for you.
3.We provide 2 days free online training.
4. Engineer fly to your site for final repair if needed.
Packaging & Shipping
dtg printer Polar-Jet fast speed top sale industrial digital tshirt printing
More information
For more information please visit www.focusdgt.com
Contact us:
Miss. Faith Wang
Tel: +86 21 67765258
Mobile: +86 177 6513 7581
Whatsapp: +86 177 6513 7581
Skype: sales6_focus
Email: sales6 @focusdgt.com
Website: www.focusgroup.en.china.cn
Don't hesitated to contact us, this is the machine you need. Please click " send " immidiately!
