Specifications
Nail making machine:1.High speed!
2.Low noise!
3.Large capacity!
4.Hot selling!
High speed nail making machine
Products introduction
The automatic nail making machine is a special purpose machine which is designed for processing various size of nails. The assortment of our products is complete. The nail machine is used for producing various nails and special nails . It has a wide range of uses , simple operation ,and reliable run. We will supply various machine fittings and the excellent supporting auxiliaries for you. This machine adopts plunger type structure and oil pipe lubrication to ensure the features such as high speed , low noise and less impact. Especially , it can make the high quality of oil rivet nail and other shaped nails used for high speed weilding nailer and nail gun.
Technical data
Technical data |
Unit |
Z94 -6.5C |
Z94 -5.5C |
Z94 -4C |
Z94 -3C |
Z94 -2C |
Z94 -1C |
Dia of nail max |
mm |
6.5 |
5.5 |
4.5 |
3.4 |
2.8 |
1.6 |
Dia of nail min |
mm |
4.5 |
3.7 |
2.8 |
1.8 |
1.2 |
0.9 |
Length of nail max |
mm |
200 |
150 |
100 |
75 |
50 |
25 |
Length of nail min |
mm |
100 |
80 |
50 |
30 |
16 |
9 |
Designed capacity |
pcs/min |
160 |
200 |
280 |
320 |
350 |
450 |
Motor power |
kw |
11 |
5.5 |
4 |
3 |
2.2 |
1.5 |
Weight(approx) |
kg |
5000 |
2500 |
2000 |
1600 |
1400 |
1200 |
| Type | Diameter of nail | Length of nail | Designed capacity | Motor | Weight(approx) | Overall dimension |
| Z94-5.5C | 3.5-5.5mm | 80-150mm | 200pcs/min | 5.5kw | 2500kg | 2500*1600*1700mm |
