Help CenterCPCY50 Rough Terrain Forklift With CUMMINS Engine
Related Products
Specifications
Off road Forklift4*4 WD forklift adopts CUMMINS engine
Working in any rough terrain.
5000kg
4000mm height,Joystick control
Qingzhou Caser TradingCo.,LTD
We Promise “Reliable machinery at a great price.
Model |
CPCY50 Forklift(with CE) |
|
|
Engine |
Model |
Xinchai 4DX21-72, CUMMINS 4TBA3.9-C100 |
Rated output(kw) |
53KW/74KW |
|
Type |
In line,vertical,water cooled,four-stroke |
|
Number of cylinders |
4 |
|
Cylinder bore |
|
|
Cylinder sroke |
|
|
Rated speed(r/min) |
2400 |
|
Method of starting |
Electric |
|
Total displacement (L) |
|
|
Rated load(kg) |
5000 |
|
Load center distance(mm) |
565 |
|
Lift height(mm) |
3000/4000 |
|
The freedom lifts the altitude(mm) |
150 |
|
Max lifts the speed(full load)(mm/s) |
372 |
|
Gate inclination angle (F/R)(°) |
6/12 |
|
Moving velocity (idling)(km/h) |
19 |
|
Max climbing power(%) |
50 |
|
Overal dimensions(L*W*H)(mm) |
5730*1905*2880 |
|
Dead weight(kg) |
8250 |
|
Min ground clearance(mm) |
310 |
|
Wheel distance(mm) |
|
|
Axle-base(mm) |
|
|
Forks the tooth size(L*W*H)(mm) |
1200*150*70 |
|
Max traction(kgf) |
2587 |
|
Max steering angle(°) |
±35° |
|
The after brige swing angle(°) |
±12° |
|
Min turning radius(mm) |
4500 |
|
Drive Mean |
Four Wheel drive |
|
|
Detailed Info Equipped with European III emissions engine, Air-conditioning(warm and cold), Triple valve pilot control system, Side shifter, Front double Wheel Adjustable steering wheel, adjustable suspension seat, A wide range of accessories available to sell | ||
CPCY50 Rough Terrain Forklift:
CPCY50 ROUGH TERRAIN FORKLIFT IS A PATENTED PRODUCT OF COMBINED TECHNOLOGY FROM CHINA AND AUSTRALIA. IT ADOPTS 4BTA3.9-C100 ENGINE FOR REDUCED NOISE AND EMISSION. IT HAS A HYDRAULIC-MECHANIC AUTOMATIC TRANSMISSION.AND STEERRING SYSTEM FOR FLEXIBLE AND EASY HANDLING. ARTICULATION JOINT(FRAME) HAS A SMALLER RADIUS IN TURNING. FULL ADJUSTABLE SUSPENSION SEAT(GLAMOUR BRAND) AND JOYSTICK CONTROL KEEP THE OPERATOR COMFORTABLE THROUGH THE LONGEST JOBS.
CPCY50 FORKLIFT ARE DESIGNED AND BUILT TO WORK IN A ROUGHT TERRAIN, EVEN IN A ROUGHEST TERRAIN WORKING CONDITIONS. IT IS SUITABLE TO OPERATE ON SOFT SOILS, PASTURES, MINE SITES AND MANY OTHER RUGGED SURFACE. IT IS A IDEAL MACHINE FOR LANSCOPES, CONSTRUCTION SITES, MINING COMPANIES,...
Scale type-specific:
- Roll over protection structure
- Strengthen front axle
- Electronic control transmission (with ZF Converter)
- Cummins Turbo Engine
- Front axle with double wheel
- Adjustable dashboard
- Grammer luxurious seat
- Lifting height 3M
Optional:
- Luxurious cabin
- Air-condition
- 3 Stage 4.5 M mast
- Optional accessory
