Color foam pipe insulation machine
Product Introduction:
EPE foam pipe is a kind of new-type foam material and it is widely used in the jacket of air consider,pipeline,heat insulation,toy guardrail,recretion places due to its high foaming ratio,good elasticity and insulation.
As a kind of new type foam filling and stem and ornamental material EPE foam stick is widely used in spring mattres,sofa back rest and top-grade clothing.It is also widely used in the filling of contracting joint in building.
Features:
1.V.F driving for speed regulation.Tandem screw with independent heating zones to insure easy operation,easy trouble shooting,precise heating and curing.
2.OMRON temperature control system.Stable and reliable.
3.Circulation water cooling.(Water tower,user to add)
4.The head employed automatic screen exchange system (with a hydraulic station) to save time and reduce wastage.About 30% may be saved.
5.Mold pressure control employed digital display and a septum pressure gage.The two systems insure stable top sheet quality.
6.Winder may overturn automatically. With meter counter for length pre-setting. Winding width is adjustable.
7.High foaming times. Imported temperature control system.
| Model | Unit | FCFPM-90 | FCFPM-105 | FCFPM-120 | FCFPM-150 | FCFPM-170 |
| Extruder | 90/55 | 105/55 | 120/55 | 150/55 | 170/55 | |
| Screw speed | r/min | 5-45 | ||||
| Foaming Ratio | 10-40 | |||||
| Product Width | mm | 800-1600 | 1000-2000 | 1000-2000 | 1000-2000 | 1000-2000 |
| Product thickness | mm | 0.5-3.0 | 0.5-5.0 | 0.8-8.0 | 1.0-10.0 | 2.0-15.0 |
| Cooling Method | Air-cooled,water-cooled | |||||
| Installed Power | kw | 90 | 100 | 120 | 150 | 180 |
| Dimension | m | 20*2.3*2.2 | 23*2.3*2.2 | 25*2.3*2.2 | 30*2.3*2.2 | 32*2.3*2.2 |
| Weight | T | 6 | 8 | 12 | 15 | 17 |
Packaging:standard export package
Q1:Will you conduce training for our staff here?
A1:Yes,we will arrange professional engineers to install and test machien and train the buyer's engineers.
Q2:How about the visiting?
A2:We are located in Longkou City,Shandong Province,China. The nearest airport is Yantai Airport.You can transfer from Guangzhou,Beijing or Shanghai airport to Yantai airport.We will pick you at the Yantai airport when you come to visit us.
Q3:Could I test machine before placing order?
A3:We will make the machine running during your visiting to check the working condition.And there are some client who bought our machine in our city.We will take you to their factory to check all working flow.
Q4:How many countries have your machine been installed?
A4:Our machines have exported many countries such as Korea,Japan,Kazakhstan,Uzbekistan,Malaysia,Russia,Poland,France,Turkey,Thailand,Vietnam,Brazil,Columbia,Argentina,Costa Rica,Algeria,Nigeria,Malawi,Bolivia,Sudan,Jordan,Egypt,South Africa,etc.
Q5:What are your terms of payment?
A5:We accept T/T,L/C,Western Union and Cash.
Q6:What's your contact way?
A6:Skype:cathy053511 Wechat:cathy053511 Mobile/Whatsapp:0086-18254510608
QQ:18254510608
Our website is:
