Diesel Generator with good quality
|
Generating Set |
Generating Set Model |
|
1000GF |
Rated power |
kW |
1000 |
|
Rated voltage |
kV |
0.4 6.3 6.6 10.5 11 13.8 |
|
Rated frequency |
Hz |
50 / 60 |
|
Rated speed |
r / min |
500 / 514 |
|
Power factor |
cos |
0.8 (lagging) |
|
Specific fuel consumption |
g/kWh |
215 ± 5% |
|
Specific lubricating-oil consumption |
g/kWh |
1.2 |
|
Overall dimensions |
mm |
7264×2300×3465 |
|
Net weight |
ton |
32.5 |
|
|
Diesel Engine |
Engine Model |
|
G6300ZD |
Type |
|
Vertical in line, 4-stroke, turbocharged, Inter-cooling diesel engine for generating set |
|
Cylinder number |
|
6 |
|
Cylinder bore × Stroke |
mm |
300 × 380 |
|
Rated power |
kW |
1125 |
|
Mean piston speed |
m/s |
6.33 / 6.51 |
|
Compression ratio |
|
13 |
|
Mean effective pressure |
MPa |
1.68 / 1.63 |
|
Rotation direction |
|
Counterclockwise (viewing from flywheel end to free end) |
1. Pre-sale service
Our engineer team helps to choose the suitable engine type to you
2. Sale service
We send engineer to help installation, debug, and training, give English type manual instruction and spare parts.
3. After-sales service
Warranty period;1year ,service online.
Zhongneng power covers an area of 48000 square meters, workshop construction area is28000 square meters; fixed asset is 150 million RMB. We have many international advanced devices, such as HEXAGON three-coordinated measuring instrument, LEICA laser tracker, ultrasonic fault detectors,2 sets of Germany-made CNC floor type boring and milling machine ,1 set of Japan-made CNC machining center,3sets of large gantry milling machine,60 sets of imported vertical and horizontal CNC machining center,400 sets of machine processing equipment.
we gurantee the quality ,welcom contact me
