Coal Gas Requirement
1). Before entering into engine, the coal gas should be appropriate filtering, gas-liquid separation and pressure regulation. If the temperature is too high, it should be through cooling treatment, and make sure there is no liquid contents in the gas.
2). Gas temperature≤40°C,Gas pressure 3~10kpa,
Pressure change rate≤1kPa/min, NH3 ≤20mg/Nm3
tar content≤50mg/Nm3,H2S content≤200mg/Nm3, Impurities particle size≤5μm,
moisture content≤40 mg/Nm3, impurity content≤30mg/Nm3,
Heat value≥4.2MJ/Nm
our advantages
- Cylinders Structure Design in Line and Upright, which means easy, simple and low cost in Maintenance;
- Large cylinder (Bore×Stroke=300×380mm) and Big displacement 215L , which means big reserve power capacity;
- Low engine speed at 500 or 600RPM, which means high reliability for continuous operation, sufficient combustion, low exhaust gas temperature and high heat efficiency;
- Naturally Aspirated (no turbocharger and Intercooler), meaning low failure rate and minimal downtime (Tar in syngas always block and damage turbocharger and intercooler);
- Stronger resistance and treatment ability against tar, meaning long term trouble free operation.
- Long Overhauling Time of 60000 hours and lifecycle of 20-25 years, which secure constant economic benefits of the syngas power plants.
Our service
1. Pre-sale service
Our engineer team helps to choose the site of power station, supply genset foundation drawing.
2. Sale service
We send engineer to help installation, debug, and training, give English type manual instruction and spare parts.
3. After-sales service
Warranty period;1year ,service online.
