Stainless Steel 304/316 ANSI/JIS/DIN Standard Valve
US$ 5.46 - 50
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Gate
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Chinese main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PN16 Swing Check Valve In QF601US$ 5.46 - 50MOQ: 1000 Pieces -
1PC SS304 Casting Ball Valve 2000 PSIUS$ 5.46 - 50MOQ: 1000 Pieces
-
DN 25 Stainless Steel High Pressure Metal Ball ValveUS$ 5.46 - 50MOQ: 1000 Pieces
-
Water Control Valve (2" NPT or BSPT or BSP or Other Thread Schrader Valve )US$ 5.46 - 50MOQ: 1000 Pieces
-
Flanged Ball ValveUS$ 5.46 - 50MOQ: 1000 Pieces
Standard or Nonstandard
Standard
Structure
Gate
Pressure
Medium Pressure
Power
Manual
Material
Other, Carbon Steel
Temperature of Media
Medium Temperature
Media
Water
Port Size
DN200
Place of Origin
Shanxi, China
Model Number
Thread valve
Brand Name
E4-HIG
Application
Other, General, Machinery
Product Description
Female threaded end: BSPT, NPT, DIN2999
| NO | Part name | Material | |
| 1 | Body | CF8M | CF8 |
| 2 | Disc | CF8M | CF8 |
| 3 | Seal ring | SS316 | SS316 |
| 4 | Snap spring | 316 | |
| 5 | Washer | PTFE | |
| 6 | Stem | SS316 | SS316 |
| 7 | Bonnet | CF8M | CF8 |
| 8 | Ptee | PTFE | |
| 9 | Gasket | PTFE | |
| 10 | Gland nut | Ss316 | |
| 11 | Hand whee | HT(C.R) | |
| 12 | Nut | SS316 | |
Specification
| Type | Normal Pressure PN ( MPa ) |
Pressure PS ( MPa ) | Working Pressure P(MPa> | ||
| Shell | Seal | P20 | P42 | ||
| Z11H-25 | 2.5 | 3.8 | 2.8 | 2.5 | 1.4 |
| Z11H-40 | 4 | 6 | 4.4 | 4 | 2.3 |
| Z11H-64 | 6.4 | 9.6 | 7 | 6.4 | 3.7 |
| Z11H-100 | 10 | 15 | 11 | 10 | 4.4 |
| Z11H-160 | 16 | 24 | 17.6 | 16 | - |
| mm | in | L | D | D1 | D2 | b | f | n- 4> d | H | DO |
| 15 | 1/2" | 152 | 95 | 66.7 | 34.9 | 14.3 | 1.6 | 4-16 | 163 | 100 |
| 20 | 3/4" | 178 | 115 | 82.6 | 42.9 | 15.9 | 1.6 | 4-19 | 193 | 125 |
| 25 | V | 203 | 125 | 88.9 | 50.8 | 17.5 | 1.6 | 4-19 | 250 | 160 |
| 32 | 1-1/4" | 216 | 135 | 98.4 | 63.5 | 19.1 | 1.6 | 4-19 | 250 | 160 |
| 40 | 1-1/2" | 229 | 155 | 114.3 | 73 | 20.7 | 1.6 | 4-22 | 291 | 180 |
| 50 | 2" | 267 | 165 | 127 | 92.1 | 22.3 | 1.6 | 8-19 | 399 | 200 |
| 65 | 2-1/2" | 292 | 190 | 149.2 | 104.8 | 25.4 | 1.6 | 8-22 | 438 | 200 |
| 80 | 3" | 318 | 127 | 28.6 | 1.6 | 8-22 | 464 | 200 | ||
| 100 | 4" | 356 | 255 | 200 | 157.2 | 31.8 | 1.6 | 8-22 | 565 | 250 |
| 125 | 5" | 400 | 280 | 185.7 | 35 | 1.6 | 8-22 | 614 | 250 | |
| 150 | 444 | 320 | 269.9 | 215.9 | 36.6 | 1.6 | 12-22 | 717 | 300 | |
| 200 | 559 | 380 | 330.2 | 269.9 | 41.3 | 1.6 | 12-26 | 930 | 350 | |
| 250 | 10' | 622 | 445 | 387.4 | 323.8 | 47.7 | 1.6 | 16-29 | 1020 | 450 |
| 300 | 12" | 711 | 520 | 450.8 | 381 | 50.8 | 1.6 | 16-32 | 1231 | 500 |
Main Dimension
| DN | 150Lb | 150LbP | 150LbR | |||||||
| mm | in | L | D | D1 | D2 | b | f | n- <pd | H | DO |
| 15 | 1/2" | 108 | 90 | 60.3 | 34.9 | 9.6 | 1.6 | 4-16 | 163 | 100 |
| 20 | 3/4" | 117 | 100 | 69.9 | 42.9 | 10.5 | 1.6 | 4-16 | 193 | 125 |
| 25 | 1" | 127 | 110 | 79.4 | 50.8 | 11.2 | 1.6 | 4-16 | 250 | 160 |
| 32 | 1-1/4" | 140 | 115 | 88.9 | 63.5 | 12.8 | 1.6 | 4-16 | 250 | 160 |
| 40 | 1-1/2" | 165 | 125 | 98.4 | 73 | 14.3 | 1.6 | 4-16 | 291 | 180 |
| 50 | 2" | 203 | 152 | 120.7 | 92.1 | 15.9 | 1.6 | 4-19 | 312 | 200 |
| 65 | 2-1/2" | 216 | 180 | 139.7 | 104.8 | 17.5 | 1.6 | 4-19 | 387 | 200 |
| 80 | 3" | 241 | 190 | 152.4 | 127 | 19.1 | 1.6 | 4-19 | 411 | 250 |
| 100 | 4" | 292 | 230 | 190.5 | 157.2 | 23.9 | 1.6 | 8-19 | 454 | 250 |
| 125 | 5" | 356 | 255 | 215.9 | 185.7 | 23.9 | 1.6 | 8-22 | 455 | 300 |
| 150 | 6" | 406 | 280 | 241.3 | 215.9 | 25.4 | 1.6 | 8-22 | 541 | 350 |
| 200 | 8" | 495 | 345 | 298.5 | 269.9 | 28.6 | 1.6 | 8-22 | 651 | 450 |
| 250 | 10' | 622 | 405 | 362 | 323.8 | 30.2 | 1.6 | 12-26 | 800 | 450 |
| 300 | 12_ | 698 | 485 | 431.8 | 381 | 31.8 | 1.6 | 12-26 | 1213 | 500 |
| 350 | 14' | 787 | 535 | 476.3 | 412.8 | 35 | 1.6 | 12-29 | 1450 | 600 |
