Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > 12V/360W Switching Power Supply, LED Power Driver

12V/360W Switching Power Supply, LED Power Driver

Name: 12V/360W Switching Power Supply, LED Power Driver
Brand: SCOTT
SKU: 116324441

12V/360W Switching Power Supply, LED Power Driver thumbnail-1

12V/360W Switching Power Supply, LED Power Driver thumbnail-2

12V/360W Switching Power Supply, LED Power Driver thumbnail-3

12V/360W Switching Power Supply, LED Power Driver thumbnail-4

12V/360W Switching Power Supply, LED Power Driver photo-1

12V/360W Switching Power Supply, LED Power Driver photo-2

12V/360W Switching Power Supply, LED Power Driver photo-3

12V/360W Switching Power Supply, LED Power Driver photo-4

US$ 16.50 - 16.50 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

SCOTT

Model Number:

SC-BX-360-12-30

Contact Supplier Request Quote Chat Now

Shenzhen Scott Electronics & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name SCOTT

Model Number SC-BX-360-12-30

Output Power 301 - 400W

Output Type Triple

Input Voltage Other, 110-220VAC

Output Voltage 12VDC

Output Frequency 50/60Hz

Output Current 30A

Specification:

Model	HS-350-5	HS-350-12	HS-350-15	HS-350-24	HS-350-27	HS-350-31
Specification
DC output voltage	5V	12V	15V	24V	27V	31V
Output voltage tolerance(Note:2)	±2%	±1%	±1%	±1%	±1%	±1%
Rated output current	70A	29A	23.2A	14.6A	13A	11.3A
Output current rage	0-70A	0-29A	0-23.2A	0-14.6A	0-13A	0-11.3A
Wave and noise(Note :3)	150mVp-p	150mVp-p	150mVp-p	150mVp-p	1500mVp-p	200mVp-p
Inlet stability(Note :4)	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
Load stablity (Note :5)	±1%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
Efficiency	78%	80%	80%	82%	82%	84%
Adjustable range for DC voltage	4.5-5.6V	10-13.2V	13.5-18V	20-26.4V	26-32V	41-56V
AC input voltage range	85~132VAC/180-264VAC 47-63Hz;254-370VDC
Input current	6.5A/115V 4A/230V
AC INrush current	25A/115V 50A/230V
Leakage current	<3.5mA/240VAC
Overload protection	105%~135% hiccup mode, auto recovery
Over voltage protection	115%-135% cut off the output, auto recovery
High-temperature protection	ERH3>=65°C~70°C Fan on,<=55°C~60°CFan off,>=80°C~85°C,Cut off output(5~15V)Cut off output(5~15)~(24~48V)
Temperature coefficient	±0.03%/°C(0~50%)
Setup rise hold up time	200ms,100ms,20ms
Vibration	10~500Hz,2G 10min,/1cycle,Period for 60min,each axes
Withstand voltage	Input and output internal:1.5KVAC,Input and enclosure:1.5KVAC,Output and enclosure:0.5KVAC
Isolation resistance	Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ
Working temperature and humidity	-10°C~+60°C(Refer to output derating curve),20%~90%RH
Store temperature and humidity	-20°C~+85°C,10%~95%RH
Overall dimension	215×115×50mm
Weight/Packing	1.15Kgs, 24pc/CTN
Note: 1.The testing condition for the parameter above is :230VAC input,rated load,25°C70% RH.Humidity. 2.Tolerance include the setting tolerance,line stability and load stability.(Note:5). 3.Wave test:adopting "A12"double wire for 20MHz,and 0.1UF&47UF capacitor short-circuit for interrupting. 4.Inlet voltage stability test:when is over load,the lowest voltage of inlet is up to the highest voltage. 5.Load stability test:the load is from 0% to 100%.
