Home > Lights & Lighting > LED Encapsulation Series > LED Module > Waterproof 5pcs 3528 SMD Module 14mm*91mm*8mm

Waterproof 5pcs 3528 SMD Module 14mm91mm8mm

Name: Waterproof 5pcs 3528 SMD Module 14mm*91mm*8mm
Brand: SCOTT
SKU: 116316733

Waterproof 5pcs 3528 SMD Module 14mm*91mm*8mm thumbnail-1

Waterproof 5pcs 3528 SMD Module 14mm*91mm*8mm photo-1

US$ 0.36 - 0.39 MOQ: 20 Pieces

Key Specifications

Get Latest Price

Model Number:

SC-3528-5

Operating Temperature(℃):

-40, 60

Storage Temperature(℃):

-20, 60

Contact Supplier Request Quote Chat Now

Shenzhen Scott Electronics & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shen zhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Model Number SC-3528-5

Operating Temperature(℃) -40, 60

Storage Temperature(℃) -20, 60

Place of Origin Guangdong, China

Brand Name SCOTT

Certification CE, CE

red / green / blue / yellow / white /warm white

LED Type	3528 SMD
Angle	≥140°
Available colors	red / green / blue / yellow / white /warm white
Color Temperature / Wavelength	red green blue yellow white warm white 619-635 512-528 463-475 484-595 5500-11000 2400-4000
Single-light flux(lm)	red green blue yellow white warm white 1.1 3 0.9 1 5 5
LED Qty (pcs)	5
Light Source Life	50000 hours
Voltage	DC12V
Power	0.48W
Drive Mode	Constant Drive
Shell	Plastic case
Shell Size	a:14918mm b:14788mm
Shell color	white
Temperature	—40°C-----------60°C
Storage Temperature	—50°C-----------80°C
IP Rank	IP65

1, the thickness and thiness of the power cord should be determined due to the actual maximum current, the product power, limited length (not recommended for more than 5 meters), and low-voltage transmission line loss.

2,The out-stretch line of both sides of the light shoule take note of waterproof.

3,Static touch is strictly prohibited,operation with power.;

4, the lamp line is up to be available for max 20pcs connection , non-super-tandem

5, the proposed use of qualified switching power supply (with short-circuit protection, overvoltage protection, overload protection)is strongly recommended.

6,Please connect following the notified positive and negative of the outter covering,the grey line for the positive power and white.for the negative power.
