0.46mm high pressure hydraulic tube wire brass coated
- 5000 Ton / Tons per Month
- Qingdao/Shanghai
- T/T D/P D/A Credit Card
Product Details
Steel Grade: | Angang wire rod | Standard: | AISI, ASTM, BS, DIN, GB, JIS | Wire Gauge: | 0.46mm |
Place of Origin: | Henan, China | Type: | Other, brass coated | Application: | Other, Netting, Hydraulic hose, high pressure hose |
Alloy Or Not: | Non-alloy | Special Use: | Cold Heading Steel | Model Number: | 0.46mm hydraulic tube wire |
Brand Name: | Hengxing |
Product Description
Specifications
hydraulic tube wire brass coated:1.high quality;
2.factory price;
3.export standard packing;
4.brass coated.
0.46mm high pressure hydraulic tube wire brass coated
Description:
The high-pressure hose wire is a kind of steel wire products of high strength, whose surface is plated with a uniform layer of brass alloy.
Raw materials:
The high-quality wire rod especially for steel cords produced by Japan KOBE, NIPPON and Germany SAARSTAHL is chosen.
Advantages:
Hengxing is specialized in developing and producing high-pressure hose wires, which have various specifications and long service life, and resist high temperature, high pressure and high impact. It has an excellent performance is all aspects.
Nominal diameter | Tolerance | Tensile strength | Torsions (L=100xø) | Reverse bends (r=2.5mm) |
mm | mm | (Mpa,N/mm2) | Min | Min |
0.2
| ±0.010 | 2150~2450 | 70 | 125 |
2450~2750 | 70 | |||
2750~3050 | 65 | |||
3050~3350 | 60 | |||
0.25
|
±0.010
| 2150~2450 | 70 | 125 |
2450~2750 | 70 | 125 | ||
2750~3050 | 65 | 105 | ||
3050~3350 | 60 | 75 | ||
0.3
| ±0.010 | 2150~2450 | 65 | 105 |
2450~2750 | 60 | 95 | ||
2750~3050 | 60 | 85 | ||
3050~3350 | 50 | 60 | ||
0.35
| ±0.015 | 2150~2450 | 65 | 60 |
2450~2750 | 60 | 60 | ||
2750~3050 | 60 | 55 | ||
3050~3350 | 50 | 50 | ||
0.4
| ±0.015 | 2150~2750 | 60 | 55 |
2450~2750 | 60 | 55 | ||
2750~3050 | 60 | 50 | ||
3050~3350 | 50 | 45 | ||
0.42
| ±0.015 | 2150 ~2450 | 60 | 50 |
2450 ~ 2750 | 60 | 50 | ||
2750 ~3050 | 50 | 45 | ||
0.46
| ±0.015 | 2150~2450 | 60 | 45 |
2450~2750 | 60 | 45 | ||
2750~3050 | 50 | 40 | ||
0.5
| ±0.015 | 2150~2450 | 60 | 40 |
2450~2750 | 60 | 35 | ||
2750~3050 | 50 | 30 |
Finished products:
Factory showing:
Packing:
General informations:
If you have any questions,please feel free to contact me as follows:
Email:wmgmk(at)
P:0086 371 66908222
Skype:flyinsky0929
Contact Us
- Gongyi Hengxing Hardware Co., Ltd.
- Contact nameTina cheng
- Phone86-371-68716999
- Address1707# D building Pufa International building, No.299 Jinshui road,Zhengzhou Zhengzhou,Henan
