NGGJ Series of Automatic Compensator Reactive Power Power Compensation
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
NingGrand
Model Number:
GGJ Low Voltage Automatic compensator reactive
Payment & Shipping
Payment Methods:
Port of Shipment:
All ports.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KYN28A-12(Z)Armored Remove AC Metal-enclosed SwitchgearNegotiableMOQ: 1 Set -
HXGN15A-12(F.R)Box-Type Fixed AC Metal-enclosed Indoor Ring Network EquipmenNegotiableMOQ: 1 Set
-
KYN61-40.5 Switchgear Power Distribution CabinetNegotiableMOQ: 1 Set
-
XGN2-12(Z) Box-type Fixed Metal-enclosed SwitchgearNegotiableMOQ: 1 Set
-
GCS,GCK ,GCL Low-voltage Withdrawable SwitchgearNegotiableMOQ: 1 Set
Place of Origin
Sichuan, China
Brand Name
NingGrand
Model Number
GGJ Low Voltage Automatic compensator reactive
Product Description
NGGJ Low Voltage Automatic compensator reactive
1, Outline
This device is mainly used to improve power quality, reactive power compensation system to improve power factor, reduce reactive power loss. The device is mainly used in reactive power compensation required users machinery manufacturing, metallurgy, mining, coal, chemical, water, building materials, living area, high-rise buildings.
This device uses a capacitor dielectric insulation material imported whole film metalized film structure and stability, non-toxic manufacturing impregnating agent. Therefore, low dielectric loss, self-healing capabilities, high reliability, small size, light weight, long life and other characteristics.
2, Type meaning
3,Normal conditions of use
1 reference standard: IEC60831-1 (1996), GB50227-1995, GB50054-1995, JB7113-1993
2 elevation ≤2000m.
3 Ambient temperature: -25 ℃ ~ + 55 ℃.
4 air relative humidity: ≤95%
5 maximum operating voltage: <1.1UN.
6 Maximum load current: <1.3IN.
7 installation location should be no severe vibration, tilt angle no greater than 5 °.
8 no explosion and the surrounding medium to flammable, non-corrosive metal and insulation damage harmful gases, non-conductive dust;
9 power system quality in line with national standards, no strong harmonics.
4,Main technical parameters
| Product Model | Rated voltage (KV) |
Rated capacity of device(kvar) | throw-cut circuit number | single circuit capacity(kvar) | Cabinet width (w) |
| NGGJ- -60/4- | 0.23 0.4 0.69 | 60 | 4 | 15 | 800 |
| NGGJ- -90/4- | 0.23 0.4 0.69 | 90. | 6 | 15 | 800 |
| NGGJ- -120/6- | 0.23 0.4 0.69 | 120. | 6 | 20 | 800 |
| NGGJ- -150/10- | 0.23 0.4 0.69 | 150 | 10 | 15 | 800 |
| NGGJ- -180/6- | 0.23 0.4 0.69 | 180. | 6 | 30 | 800 |
| NGGJ- -180/9- | 0.23 0.4 0.69 | 180 | 9 | 20 | 800 |
| NGGJ- -200/10- | 0.23 0.4 0.69 | 200 | 10 | 20 | 800 |
| NGGJ- -240/8- | 0.23 0.4 0.69 | 240. | 8 | 30 | 1000 |
| NGGJ- -270/9- | 0.23 0.4 0.69 | 270 | 9 | 30 | 1000 |
| NGGJ- -300/10- | 0.23 0.4 0.69 | 300. | 10 | 30 | 1000 |
| NGGJ- -360/12- | 0.23 0.4 0.69 | 360 | 12 | 30 | 1000 |
| NGGJ- -400/12- | 0.23 0.4 0.69 | 400. | 16 | 25 | 1000 |
