Electric Boiler, Electric Water Boiler and Steam Boiler

Name: Electric Boiler, Electric Water Boiler and Steam Boiler
Brand: Xingfu
SKU: 116248649

US$ 10,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Natural Circulation, Electric Steam Boiler

Usage:

Other, Home application

Qingdao Xingfu Boiler Thermoelectric Devices Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Natural Circulation, Electric Steam Boiler

Usage Other, Home application

Structure Other, Vertical

Pressure Low Pressure

Style Vertical

Fuel Other, Electric

Place of Origin Shandong, China

Brand Name Xingfu

Model Number ZDR Series Electric Boiler

Output Hot Water

Dimension(L*W*H) Depend on the Boiler Type

Weight 0.2--3.5T

Certification ISO14001,CE,SGS and ASME

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Electric Boiler

Electric Steam Generator
	Rated Evaporation T/H	Rated Steam Pressure Mpa	Rated Steam Temp. ℃	Feed Water Temp ℃	Power of Single Electric Heater Tube Kw	Rated Incoming Current A	Thermal Efficiency %	Test Hydraulic Pressure Mpa	Max Transportation Weight T	Max Transportation Dimension (LWH)Mm
ZDRQ0.5	0.5	0.7	170	20	12	548	95	1.05	1.5	3170×1200 ×1312
ZDRQ1.0	1.0	0.7	170	20	12	1095	95	1.05	2.6	3620×1550 ×2072
ZDRQ2.0	2.0	0.7	170	20	12	1642	95	1.05	3.6	4850×1730 ×1662
Pressure-Bearing Electric Hot Water Boiler
	Rated Thermal Power Kw	Rated outlet Water Pressure Mpa	Rated Outlet Water Temp ℃	Rated returned Water Temp ℃	Power of Single Electric Heater Tube Kw	Rated Incoming Current A	Thermal Efficiency %	Test Hydraulic Pressure Mpa	Max Transportation Weight T	Max Transportation Dimension (LWH)Mm
ZDR0.36	360	0.7	95	70	12	547	95	1.05	0.997	2090×1150 ×1222
ZDR0.45	450	0.7	95	70	12	683	95	1.05	1.2	2090×1150 ×1222
ZDR0.72	720	0.7	95	70	12	1095	95	1.05	2.6	3620×1550 ×1472
ZDR1.44	1440	0.7	95	70	12	1642	95	1.05	2.771	4850×1730 ×1662
