Sootblower for Boiler

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port FOBQingDao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	happiness
Model Number	HXG-5		Type	Other, soot blower

Product Description

Specifications

otblower for boiler
The Model HXG-5 Rotating Sootblower is applied to the cleaning of the surfaces of steam generating tube

sootblower for boiler

The Model HXG-5 Rotating Sootblower is applied to the cleaning of the surfaces of steam generating tubes.

The HXG-5 Sootblowr is designed for cleaning while rotating. The drive unit supplies motivation for he blowing rotation and cam controls angle of blowing and the control box regulates the number of blowing revolutions. A pre-cut cam located at the rear of the drive gear that is rotated clockwise actuates the trigger and opens the blowing medium valve to supply blowing medium for elements. The blowing medium valve is a major part of the blower, which a disc is mounting inside the valve o adjust pressure at nozzles as per actual requirements. The multi-nozzled element is so positioned with respect to the boiler tubes that each nozzle is directed down a specific tube lane as the element is rotated through its blowing cycle. The elements are furnished in several different materials depending on boiler temperature and ocations. The blower valves are furnished in several different materials depending on different pressure-temperature applications.

Specification
Blowing coverage	90-335º
Element Rotation Speed	≤2.8rpm
Blowing Radius	1-1.5m
Bloeing Mesium Pressure	according to the buyer's request
Blowing Medium Flow	30-100kg/min
Motor	180w
