Industrial coal fired steam boiler
The DZL series quickly installed steam boiler is the most advanced water-fire tube boiler in Chinese market, with high efficiency, small in size and long working life for 20 years.
The boiler after improvement takes use of structure of wing type smoke duct, one-way screwed smoke tube, arched tube plate, smoke and gas separation room and several other advanced technolog, which has increased the water circulation speed and safety factor.
This boiler series is well designed, compactly made up, quickly installed, mono layer, so that the civil engineering and investment could be saved. These improvement ha extend th boiler's working life and make it the national energy saving product.
1-6 T/h steam boiler usally transported as one part, and boiler before 8 t/h(including 8 t/h)are transported as up body and bottom body(chain grate) .
Boiler parameter
|
Item Boiler type |
DZL2-0.7/1.25/1.6-AII |
DZL4-1.25/1.6/2.5-AII |
DZL6-1.25/1.6/2.5-AII |
DZL8-1.25/1.6/2.5-AII |
DZL10-1.25/ 1.6/2.5-AII |
DZL20-1.25/ 1.6/2.5-AII |
||
Evaporation capacity |
T/h |
2 |
4 |
6 |
8 |
10 |
20 |
|
Working pressure |
Mpa |
1.25/1.6 |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
|
Steam temperature |
℃ |
194/204 |
194/204/226 |
194/204/226 |
194/204/226 |
194/204/226 |
194/204/226 |
|
Inlet water temperature |
℃ |
20 |
20 |
20 |
105 |
105 |
105 |
|
Heating efficiency |
% |
≥78 |
≥78 |
≥80 |
≥80 |
≥80 |
≥82 |
|
Area of stoker |
M² |
3.2 |
5.14 |
7.4 |
9.6 |
11.4 |
23.15 |
|
Coal available |
|
AII, low heat value: 17700-21000 KJ/kg |
||||||
Water pump |
Model |
|
1½GC5×7 |
1½GC5×7 |
2GC-5×6 |
2½GC6×6 |
DG12×7 |
DG25-35×5 |
Motor power |
Kw |
7.5/11 |
7.5/11/18.5 |
15/18.5 |
15/18.5 |
18.5/22 |
30/37 |
|
Blast fan |
Model |
|
G6-41-13 NO5.4A |
G6-41-13 NO6.4A |
G6-41-13 NO7.1A |
G6-41-13 NO8.5A |
G6-41-13 NO8.5A |
TG20-1 |
Ventilation |
M³/h |
4358-2310 |
7358-3596 |
10354-5394 |
18137-9369 |
18137-9367 |
32079 |
|
Wind pressure |
Pa |
994-1254 |
1181-1436 |
1697-2270 |
2535-3391 |
2535-3391 |
2559 |
|
Motor power |
Kw |
3 |
5.5 |
7.5 |
18.5 |
18.5 |
37 |
|
Induced draft fan |
Model |
|
Y6-41-13 NO5.4C |
Y6-41-13 NO7.1C |
1Y6-41-13 NO10C |
Y6-41-13 NO11.2D |
Y6-41-13 NO11.2D |
GY20-15 |
Ventilation |
M³/h |
8901-4350 |
15219-8171 |
32144-16607 |
41773-21578 |
41773-21578 |
73308 |
|
Wind pressure |
Pa |
2568-3240 |
2454-3283 |
2574-3444 |
2764-3697 |
2764-3697 |
3515 |
|
Motor power |
Kw |
11 |
22 |
37 |
45 |
55 |
110 |
|
Maximum size for shipment |
M |
5.82×2.1×3.2 |
6.5×2.66×3.52 |
6.7×3×3.54 |
8.0×3.2×3.58 |
8.45×3.2×3.58 |
10×4.8×3.55 |
|
Maximum weight for shipment |
T |
18/19/20 |
27/29/31 |
32/33/34 |
42/43/44 |
45/47/49 |
||
