Home > Products > Spring Steel > Top Quality And Factory Price 67SiCr5 Spring Steel
Top Quality And Factory Price 67SiCr5 Spring Steel
- 100 Metric Ton / Metric Tons per Month
- Dalian
- T/T
Product Details
Steel Grade: | 60Si2CrVA | Standard: | AISI, ASTM, BS, DIN, GB, JIS | Wire Gauge: | 0.5-5mm |
Place of Origin: | Liaoning, China | Type: | Galvanized | Application: | Other, Manufacturing, spring, coiled spring, axle |
Alloy Or Not: | Is Alloy | Special Use: | Cold Heading Steel | Model Number: | 67sicr5 |
Brand Name: | DongBei TeGang |
Product Description
GB 60Si2CrVA/DIN 54SiCrV6(1.8152)
Under high stress and temperature in spring 300 to 350 DEG C for 60Si2CrVA spring steel, such as governor spring, steam turbine steam seal spring, crushing machine with spring. 60Si2CrVA steel is also used to make very important spring, such as conventional weapons bullet hook spring, crusher spring.
Product Basic Information:
Material | 60Si2CrVA | ||
Chemical Composition | Mechanical Properties(In Quenched & Tempered State) | ||
C | 0.56-0.64 | Tensile strength(MPA) | ≥1862 |
Si | 1.4-1.8 | Yield strength (MPA) | ≥1666 |
Mn | 0.40-0.70 | Elongation(δ5/%) | ≥6 |
Al | - | Reduction in Area (ψ/%) | ≥20 |
Ti | - | Impact (J) | - |
P | ≤0.035 |
Hardness | ≤321HB |
S | ≤0.035 | ||
Cr | 0.70-1.00 | ||
Ni | ≤0.35 | ||
V | 0.10-0.20 | ||
Cu | ≤0.25 | ||
N | - |
2.Product Application Areas:
Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,
electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
3.Similar steel grade & equivalent steel materials:
USA | Japanese | Gemany | British | France | International | Chinese |
ASTM&AISI&SAE | JIS | EN DIN | EN BS | EN NF | ISO | GB |
- | -
| 54SiCrV6(1.8152) | - | 60Si2CrVA |
High strength and resistance to intergranular corrosion and chloride stress corrosion is improved obviously. Stainless steel has great corrosion performance.
Product Sales Information:
Grade | 60Si2CrVA Spring Steel |
Size | Diameter:0.5-5mm |
Origin place | Made In China |
Delivery Condition | Hot rolled,cold drawn,forged |
Surface require | Black,grinding,bright,polish |
Heat treatment | Quenched,Tempered,annealed |
Packing | seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
Delivery time | In 10-50 days |
Trade Term | EXW,FOB,CIF |
Payments | T/T or L/C at sight |
Port | China main Port,such as shanghai,Dalian,Shenzhen port. |
MOQ | 1 Ton |
Company Main Products:
Alloy Steel | 5140,5115,5120,5130,5145,4118,4130,4135,6150,5115,4142,4130,4118,6150,4140,4720,4320 ,E9310,8620,4340 |
Tool Steel | H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419, SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
Bearing Steel | GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50 |
Spring Steel | 9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150, SUP10,51CrV4,1.8159 |
Stainless Steel | 321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028, 434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057,201,202,301 |
