US$ 1,400 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Table Panel Saw
Use:
Woodworking
Contact Supplier Request Quote Chat Now
Jinan Sange CNC Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Table Panel Saw
Use Woodworking
Style Horizontal
Place of Origin Shandong, China
Brand Name Sange
Model Number SG-2837
Usage Woodworking
Voltage 220V/380V
Power(W) 5.5kw
Dimension(L*W*H) 2800*375mm
Weight 500KG
Certification CE,ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas



sliding table saw cutting machine panel saw , wood cutting machine for wooden design



sliding table saw cutting machine panel saw , wood cutting machine for wooden design



Features of wood cutting machine:



1. Max. adjustable angle of main saw blade: 45° or 90°

2. Slide rail type: Altendrof structure (A), round rod structure(D) or linear structure(Z).

3. Saw blade lifting and tilting system (manual or electric)

4. Sliding table length from 1500mm to 3800mm (usually we have 1600, 2200, 2600, 2800, 3000, 3200, 3800mm).

5. All the sliding table saw have CE certification.

sliding table saw cutting machine panel saw , wood cutting machine for wooden design

sliding table saw cutting machine panel saw , wood cutting machine for wooden design

sliding table saw cutting machine panel saw , wood cutting machine for wooden design

Technicial Parameter of wood cutting machine:

Dimension of sliding table 2800*375mm
 Gross cut capacity 2800mm
 Width of cut between saw blade and rip fence 1250mm
 Saw blade diameter 300mm(250-300)
 Height of cut (diameter:300mm) 85mm
 Height of cut with saw blade 300mm at 45 angle 55mm
 Speed of main saw spindle 4000/6000rpm
 Main spindle diameter 30mm
 Tilting saw blade 45 degree
 Main motor 5.5kw
 Scoring saw blade diameter 120mm
 Speed of scoring saw blade 8000r/min
 Scoring spindle diameter 20mm
 Scoring motor 0.75kw
 Net weight 800kg
 Gross weight(with wooden package) 950kg
 Overall dimensions 2800*3150*900mm



Applications of wood cutting machine:

The woodwoking sliding table saw is apply to processing all kinds of fiberboards,flake boards,

wood-based panels,ABS boards,PVC boards,acryl glass board and the solid wood etc,or the

panels with similar hardness.
