representative agent wanted automatic roll laser fabric cloth cutting machine
---This auto feeding laser cloth cutting machine is available for engraving and cutting cloth toys,leather,wool,fabric, textile ,foam,rubber and plastic.
Technical Parameters:
NO. |
Description |
fabric laser cloth cutting machine |
1 |
Working Area |
1600x1000mm--can be customized |
2 |
Laser Power |
60W/80W/100W |
3 |
Laser Type |
CO2 sealed laser tube |
4 |
Engraving Speed |
8m/min |
5 |
Cutting Speed |
7m/min |
6 |
Power supply |
220V/50HZ 110V/60HZ |
7 |
Min. shaping character |
English 1.0*1.0mm |
8 |
Graphic format supported |
BMP, PLT,DST,DXF,AL |
9 |
Software supported |
CorelDraw,PhotoShop,AutoCAD,TAJIMA |
10 |
Driving motor |
stepper motor |
11 |
Operating System Platform |
Windows XP Vista |
12 |
Running Environment |
Temperature:0 degree~45 degree |
13 |
Control system |
Leetro/Ruida |
14 |
Color separation |
Yes |
15 |
Net Weight |
600KG |
Machine features of cloth cutting machine
1.To meet the demands of cutting in large scale,NC Series auto-feeding laser cutting bed adopts steady chassis to ensure precision and stability.
2.Liner guide rail and precision gear for transmission to ensure accuracy and high speed, open stainless meshed worktable to ensure convenient operation and wear resistance.
3.With this auto feeding system can save cost and improve efficiency.
4.The laser light of this machine will be adjusted automatically to match speed , ensuring the cutting quality in corner.
5.This machine has continuous curve cutting function, which can cut curve at a high speed of 24m/min.
Applicable Industries and materials
Applicable materials:
Cloth, leather, garments, paper, wood, acrylic, organic glass, plastic, rubber, marble, compound material and other nonmetal materials etc.
Applicable industries:
Garment, clothing, leather, furniture, package, printing, advertisement, decoration, architecture, paper product, mould, etc.
Hot sale products
|
Laser cutting machine ---Blade working table ---It can cut acrylic,wood,MDF & hard board materials.
|
|
Laser engraving machine ---Honeycomb working table ---It can cut or engraver cloth,paper , leather, rubber soft materials. |
|
If you are interested in our products
Click here to send us the message
We have someone who tell you solutions Products!
FAQ
1, How to pay the fabric cloth laser cutting machine to you ?
T/T inadvance or by ESCROW . We can accept 30% deposit , and balance paid to us before delivery machine to you .
2, How long is the fabric cloth laser cutting machine delivery time?
For standard machines, it would be 15 days; For non-standard machines and customized machines according to clients specific requirements, it would be 30 days.
3, Do You Arrange Shipment For fabric cloth laser cutting machine ?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
4,How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, How is the packing of automatic roll laser fabric cloth cutting machine ?
Water-proof plastic film package with foam protection in each corner Solid Seaworthy Wood Box Package with Steel Belt Save space as much as possible for container loading
Welcome to visit our factory for automatic roll laser fabric cloth cutting machine !
