Anti-terrible environment best techniques led display control card

Technical parameters:

Product application
Support CDMA 2000 1x EV-DO(Rev-A), WCDMA(HSDPA/HSUPA)and the same pattern mobile network in the world. What’s more, is downward-compatible with CDMA and GPRS network.
BX-3G product could access to high-speed network, as to transfer data smoothly; Widely used in all kinds of remote control and data transferring.
Product status: in March, 2014

Product model
BX-3GW (WCDMA)
BX-3GE (EVDO)

Product feature
Best techniques and quality
Anti-terrible environment.Environment temperature:-40℃~80℃
Support firmware update online

Product advantage
BX-3G Industrial wireless router widely used in LED lintel full color screens and LED Media full color screens. In the cluster sending system application area of LED full color screens, BX-3G owns it’s advantages:
1. Support the same pattern mobile network in the world (Details: check the “BX-3G user manual”)
    WCMA module: UMTS/HSDPA/HSUPA   850/1900/2100Mhz
                                 GSM/GPRS/EDGE   850/900/1800/1900MHz
    EVDO module: Double band  800/1900MHz
2. High speed access
    WCDMA adopts HSDPA/HSUPA access, and offer DL 7.2Mbps/UL 5.76Mbps;
    EVDO adopts EVDO RevA access, offer DL 7.2Mbps/UL 5.76Mbps;
3. Industrialized design
    Adopt high performance wireless module
    Adopt metal shell; Level of protection IP30, used for industrial control field
    Environment temperature: -40℃~80℃
4. High reliability
    Detect the wireless link status in real time; Will re-dial automatically when it lost connection;
    Guarantee the equipment keeping usability
    With the design of anti-interface, anti-static, and it could used for wicked electromagnetic environment
5. Simple operation and it’s convenient for maintenance

Product functions
Support APN dialing by operator’s private network
Support network protocols of TCP/UDP, DHCP, ICMP, ARP, DNS, etc.
Support DDNS
Support port mapping and DMZ
Support static addresses distributing and static router configurating
Self-contained firewall function
Support the configurations of message/WEB/webmaster platform, and support data back-up and lead-in
Support firmware remote online updating
Self-contained factory reset function

Technical Parameters
Average power ≤4W (The instant peak current 1.5A)
Receiving sensitivity ≤-107dBm
Working power 5V (4V-6.5V)
Working Temperature -40℃~80℃
