1) High stabilization;
2) 270, 1000, 2000 Hz Tone
3) Low battery indicator
4) Battery charge indicator
5) FC/PC or customise;
6) Energy save mode: about 10 minutes
no operation will cause the device
automatic power off (can be cancelled);
7) Full energy can support above 16
hours operation;
Model Options:
AOS200-X-Y, AOS200-XX-Y, AOS200-XXX-Y
X |
M8 |
M3 |
S3 |
S4 |
S5 |
S6 |
Wavelength |
850nm |
1300nm |
1310nm |
1490nm |
1550nm |
1625nm |
Y |
V01 |
V10 |
VFL |
1mW |
10mW |
Example:
AOS200-M8, it has single wavelength 850nm only
AOS200-S3S5, it has two wavelength1310nm,1550nm
AOS200-S3S4S5-V01, it has three wavelength 1310nm, 1490nm, 1550nm and 1mW VFL
Main Characteristic
|
AOS200 |
Stabilization* |
±0.05dB / 1 hour; ±0.1dB / 8 hours |
Output Power |
> - 6 dBm @1310/1490/1550/1625 |
> - 10 dBm @1300/850 | |
Modulation |
270Hz, 1KHz, 2KHz |
Connector |
FC/PC (or customise other connectors) |
Auto Power Off |
No operation in 10 minutes (can be cancelled), Low battery energy |
Build in VFL (Optional) |
1mW or 10mW or customize |
Wave ID |
Should be used with the power meter AOP100 optional function |
Battery Charge |
Yes |
Operate Time |
Above 16 hours |
Storage Temperature |
-20 -- +60 °C, < 90%RH |
Operating Temperature |
-10 -- +50 °C, < 90%RH |
Power Supply |
AA * 2 batteries or AC/DC power supply adapter |
Size |
170mm * 97mm * 38mm |
Weight |
About 380g |
* After 5 minutes warm-up, 20±3°C, CW, FC connector, with optic isolator
Accessories
Standard |
Carrying bag |
1 |
User’s manual |
1 |
|
Calibration certification |
1 |
|
Optional |
AC/DC adaptor |
1 |
